Marantz DV9500 - Page 168

166
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PM01 RU48 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU49 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU52 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU53 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU54 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU55 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU56 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 RU57 ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
PM01 RU66 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU67 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU69 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 RU71 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 RU72 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU73 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU74 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU75 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU76 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU77 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU78 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU79 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU80 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU81 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PM01 RU82 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PM01 RU83 ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
PM01 RU84 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PM01 RU85 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PM01 RU87 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU92 /N1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU92 /N1S ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU93 /F1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU93 /F1N ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU93 /L1G ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU93 /S1G ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 RU93 /U1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 SU01 00MSS04040140 00MSS04040140 SLIDE SWITCH CHS-04TB1 DIP SWITCH
(
4TERMINAL
PM01 X101 00MJX27001350 00MJX27001350 CRYSTAL 27MHZ X-TAL
PM01 X301 00MJX12001350 00MJX12001350 CRYSTAL 12.288MHZ X’TAL
(
SMD-49
)
PM01 XU01 00MFQ01205050 00MFQ01205050 SERAMIC VIB. CSTCE12M0G52-R0
PT01 CT01 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT02 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT03 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
PT01 CT04 ns
p
00MDD95470300 CERAMIC CAP. 47 PF +- 5 % CG 50V GR39
PT01 CT05 ns
p
00MDD95470300 CERAMIC CAP. 47 PF +- 5 % CG 50V GR39
PT01 CT06 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
PT01 CT07 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT08 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CT09 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT10 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT11 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT12 00MEY22600670 00MEY22600670 TANTL.CAP CHIP MSVAOJ 22UF 6.3V TANTAL CAP
PT01 CT13 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT14 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT15 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CT16 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT17 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
PT01 CT18 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT19 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT20 00MEY22600670 00MEY22600670 TANTL.CAP CHIP MSVAOJ 22UF 6.3V TANTAL CAP
PT01 CT21 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT22 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT24 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT25 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CT26 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT27 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CT28 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT29 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CT30 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
