167
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PT01 CT31 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CT32 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT51 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PT01 CT52 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CT54 ns
p
00MDK98105200 CERAMIC CAP. 1UF 10V F
PT01 CT57 ns
p
00MOA47601640 ELECT. CAP. 47UF 16V ARS-TYPE ELN
A
PT01 CT58 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW01 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW02 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW03 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW04 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW05 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW06 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW07 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW08 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW09 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW10 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW11 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW12 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW13 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW14 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW15 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW16 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW17 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW18 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW19 00MEY33403510 00MEY33403510 TANTL.CAP CHIP 0.33UF/ 35V
PT01 CW20 ns
p
00MDK96333200 CERAMIC CAP. 0.033UF +- 10%
PT01 CW21 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW22 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW23 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW24 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW25 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW81 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CW82 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW83 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW84 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW85 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CW86 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW87 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW88 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW89 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PT01 CW90 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 CW91 00MEY10700620 00MEY10700620 ELECT. CHIP 100UF/6.3V
PT01 CW92 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PT01 JT01 00MYJ90014600 00MYJ90014600 JACK DC1R019JDA HDMI TERMINA
L
PT01 JT51 00MYJ90014610 00MYJ90014610 JACK YKC22-0748N OPT+1P RCA 5
V
PT01 JW01 00MYJ07060190 00MYJ07060190 JACK 40FLT-SM1-TB
PT01 LT01 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PT01 LT02 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LT03 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PT01 LT04 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LT05 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LT06 00MFN21000070 00MFN21000070 EMI FILTER ACM2012H-900-2P
PT01 LT07 00MFN21000070 00MFN21000070 EMI FILTER ACM2012H-900-2P
PT01 LT08 00MFN21000070 00MFN21000070 EMI FILTER ACM2012H-900-2P
PT01 LT09 00MFN21000070 00MFN21000070 EMI FILTER ACM2012H-900-2P
PT01 LT51 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LW01 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LW02 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PT01 LW03 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PT01 QT01 00MHC10247990 00MHC10247990 IC SII9190 HDMI TRANSMITTER
PT01 QT02 00MHC008905K0 00MHC008905K0 IC TC7SZ08FU
PT01 QT03 00MHY22010050 00MHY22010050 CHIP FET HN1K05FU 2SK2824 X 2
PT01 QT05 00MHC91A33770 00MHC91A33770 IC RN5RZ33BA-TR
PT01 QT06 00MHC10031770 00MHC10031770 IC RN5RZ50B-TR
PT01 QT51 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PT01 QW01 00MHC10020660 00MHC10020660 IC PD0280B SCALER
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
