Marantz DV9500 - Page 170

168
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PT01 QW02 00MHC10384050 00MHC10384050 IC TC7S66FU
PT01 QW03 00MHC10384050 00MHC10384050 IC TC7S66FU
PT01 QW81 00MHC91903210 00MHC91903210 IC BA033SFP 3.3V WITH-SW LOW-SATU
PT01 QW82 00MHC91A33770 00MHC91A33770 IC RN5RZ33BA-TR
PT01 QW83 00MHC10228210 00MHC10228210 IC BA25BC0WFP 2.5V REG.
PT01 RT01 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT02 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT03 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT07 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RT08 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RT09 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PT01 RT11 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 RT12 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 RT13 ns
p
00MNN05561610 CHIP RESISTOR 560 OHM +- 5% 1/16
W
PT01 RT14 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RT15 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RT16 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RT17 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RT18 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RT19 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RT20 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PT01 RT21 ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
PT01 RT22 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 RT23 ns
p
00MNN05182610 CHIP RESISTOR 1.8K OHM +- 5% 1/16
W
PT01 RT24 ns
p
00MNN05182610 CHIP RESISTOR 1.8K OHM +- 5% 1/16
W
PT01 RT25 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT26 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT29 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 RT30 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 RT31 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT32 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT33 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT34 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT35 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT36 00MNP05510610 00MNP05510610 CHIP RESISTOR 51 OHM +- 5% 1/16
W
PT01 RT37 00MNP05220610 00MNP05220610 CHIP RESISTOR 22 OHM +- 5 % 1/16
W
PT01 RT38 00MNP05220610 00MNP05220610 CHIP RESISTOR 22 OHM +- 5 % 1/16
W
PT01 RT39 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PT01 RT51 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RT52 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT53 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PT01 RT54 ns
p
00MNN05182610 CHIP RESISTOR 1.8K OHM +- 5% 1/16
W
PT01 RT55 ns
p
00MNN05392610 CHIP RESISTOR 3.9K OHM +- 5% 1/16
W
PT01 RT56 ns
p
00MNN05221610 CHIP RESISTOR 220 OHM +- 5% 1/16
W
PT01 RT57 ns
p
00MNN05680610 CHIP RESISTOR 68 OHM +- 5% 1/16
W
PT01 RT58 ns
p
00MNN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16
W
PT01 RT59 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT60 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RT61 ns
p
00MNN05221610 CHIP RESISTOR 220 OHM +- 5% 1/16
W
PT01 RW01 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RW02 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RW03 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW04 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW05 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW06 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW07 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RW08 00MBW05220020 00MBW05220020 RESISTOR COMPO. CN1J4KTD22J
PT01 RW11 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW12 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW13 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW14 ns
p
00MNN05332610 CHIP RESISTOR 3.3K OHM +- 5% 1/16
W
PT01 RW15 ns
p
00MNN05821610 CHIP RESISTOR 820 OHM +- 5% 1/16
W
PT01 RW16 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PT01 RW17 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PT01 RW18 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PT01 RW20 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PT01 RW21 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
