169
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PT01 RW22 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PT01 RW23 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PT01 TR1 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
PT01 TR2 00MBA20035210 00MBA20035210 CHIP TR. DTC114EUA
PT01 R1 ns
p
00MNN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16
W
PT01 R2 ns
p
00MNN05392610 CHIP RESISTOR 3.9K OHM +- 5% 1/16
W
PT01 R3 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PT01 R4 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PV01 CE01 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE01 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE02 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE02 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE03 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE03 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE04 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE04 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE05 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE05 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE06 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE06 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE07 /N1B ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE07 /N1S ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE08 /N1B ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE08 /N1S ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE09 /N1B ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE09 /N1S ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE10 /N1B ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE10 /N1S ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE11 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE11 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE12 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE12 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE13 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE13 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE14 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE14 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE15 /N1B ns
p
00MOA22605020 ELECT. CAP. 22 UF M 50V RA-2
PV01 CE15 /N1S ns
p
00MOA22605020 ELECT. CAP. 22 UF M 50V RA-2
PV01 CE16 /N1B ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE16 /N1S ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE17 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE17 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE18 /N1B ns
p
00MOA10800620 ELECT. CAP. 1000UF 6.3V M RA-2
PV01 CE18 /N1S ns
p
00MOA10800620 ELECT. CAP. 1000UF 6.3V M RA-2
PV01 CE19 /N1B ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE19 /N1S ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE20 /N1B ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE20 /N1S ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE21 /N1B ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE21 /N1S ns
p
00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
PV01 CE22 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE22 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE24 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE24 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE25 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE25 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE26 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE26 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE27 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE27 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE32 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE32 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE33 /N1B ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE33 /N1S ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PV01 CE90 /N1B ns
p
00MDD95331300 CERAMIC CAP. 330 PF +- 5 % CG 50
V
PV01 CE90 /N1S ns
p
00MDD95331300 CERAMIC CAP. 330 PF +- 5 % CG 50
V
PV01 CE91 /N1B ns
p
00MDD95331300 CERAMIC CAP. 330 PF +- 5 % CG 50
V
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
