Marantz MD-19 - Exploded View and Parts List

26
8. EXPLODED VIEW AND PARTS LIST
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
001B BLACK FRONT PANEL ASSY 362K248500
001B GOLD FRONT PANEL ASSY 362K248510
002B BLACK FRONT PANEL AL 362K248010
002B GOLD FRONT PANEL AL 362K248110
003B BLACK ESCUTCHEON
CORNER COLUMN PL LEFT
342K063010
003B GOLD ESCUTCHEON
CORNER COLUMN PL LEFT
342K063110
004B BLACK ESCUTCHEON
CORNER COLUMN PL RIGHT
342K063020
004B GOLD ESCUTCHEON
CORNER COLUMN PL RIGHT
342K063120
015B BLACK 4822 450 10141 WINDOW BLUE SMOKE 318K158010
015B GOLD 4822 450 10143 WINDOW PINK SMOKE 318K158110
017B BLACK LENS 290J355010
017B GOLD LENS 290J355110
019B BLACK BUSHING POWER 362K259010
019B GOLD BUSHING POWER 362K259110
021B BLACK BUSHING EJECT 362K259020
021B GOLD BUSHING EJECT 362K259120
031B BLACK BUTTON PLAY/STOP/PAUSE 362K270010
031B GOLD BUTTON PLAY/STOP/PAUSE 362K270110
033B BLACK BUTTON EJECT 362K270020
033B GOLD BUTTON EJECT 362K270120
035B BLACK BUTTON POWER 362K270030
035B GOLD BUTTON POWER 362K270130
037B BLACK BUTTON MONITOR 362K270040
037B GOLD BUTTON MONITOR 362K270140
039B HOLDER FOR FL 356K271010
041B 4822 459 10942 STICKER 056J122020
043B BLACK KNOB TIMER 362K154040
043B GOLD KNOB TIMER 362K154140
051B NUT FOR HEADPHONE JACK 139S011010
061B BLACK KNOB ENCORDER 362K154010
061B GOLD KNOB ENCORDER 362K154110
063B BLACK KNOB REC LEVEL 362K154020
063B GOLD KNOB REC LEVEL 362K154120
065B BLACK KNOB REC BALANCE 362K154030
065B GOLD KNOB REC BALANCE 362K154130
067B BLACK 4822 411 20336 KNOB INPUT/H.P.VOLUME 284T154310
067B GOLD KNOB INPUT/H.P.VOLUME 284T154240
005G LEG 299J057110
007G LEG 299J057120
911G BLACK 4822 532 52145 BUSHING MAINS CORD 1455259210
911G GOLD 4822 532 60948 BUSHING MAINS CORD 450H259010
001M MECHANISM MD UNIT
KMK-260AAA
354K304500
002M 4822 492 11702 SPRING FOR MECHA 354K115010
003M BLACK DOOR FOR MECHA 354K162020
003M GOLD DOOR FOR MECHA 362K162110
004M 4822 535 10584 SHAFT FOR MECHA 354K112010
W101 JUMPER LEAD YU16120520
W701 JUMPER LEAD 19P 180MM YU19180500
W721 JUMPER LEAD 16P 180MM YU16180500
PACKING
001T F USER GUIDE 362K851110
001T K USER GUIDE 362K851350
T001 REMOTE COMMANDER
RC-19MD
ZK362K0010
NOT STANDARD SPARE
PARTS
001S FB PACKING CASE MD-19 BL 362K801010
001S FN PACKING CASE MD-19 GL 362K801020
003S CUSHION BOTH SIDE 318K809010
W001 4822 321 62205 CONNECTIVE CORD
RCA ST.CORD 1M
ZD01000550
W002 4822 321 62205 CONNECTIVE CORD
RCA ST.CORD 1M
ZD01000550
W003 4822 321 62012 CONNECTIVE CORD RCA
RC-5 CORD 0.9M
ZD00900100
W004 CONNECTIVE CORD
OPT CABLE P2187-60A
ZD00600080
W601 F MAINS CORD YC01800430
W601 K 4822 321 11343 MAINS CORD YC01800790
001M : The MD UNIT (Part No. 354K304500) is already attached with a door for MD2020.
Please replace the door (003M) for MD-19 .
001M : このMDUNIT(PartNo.354K304500)についているDOORはMD2020用です。
MD‑19用のDOOR003Mに交換してください
