Marantz MD-19 - Page 27

31
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q475 4822 130 63601 CHIP TR. 2SC4213 HX342132A0
Q476 4822 130 63601 CHIP TR. 2SC4213 HX342132A0
P403-MISCELLANEOUS
F471 FERRITE CORE
BK1608HM102-T
FC90020120
F472 FERRITE CORE
BK1608HM102-T
FC90020120
F473 FERRITE CORE
BK1608HM102-T
FC90020120
J471 FB KBL 4822 267 31692 H.P JACK HLJ0540-01-410 BLK YJ01003870
J471 FN KGL 4822 267 31692 H.P JACK HLJ0540-01-430 GRY YJ01003880
P406-MAIN CIRCUIT BOARD
P406-CAPACITORS
CH01 FILM CAP 1500pF ±5% OF15152540
CH02 FILM CAP 1500pF ±5% OF15152540
CH03 FILM CAP 180pF ±5% OF15181540
CH04 FILM CAP 180pF ±5% OF15181540
CH05 4822 126 11671 CER. CHIP 33pF ±5% CG 50V DD95330300
CH06 4822 126 11671 CER. CHIP 33pF ±5% CG 50V DD95330300
C301 4822 126 12339 CER. CHIP 2200pF ±10% DK96222300
C302 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C303 4822 126 11695 CER. CHIP 330pF ±5% CG 50V DD95331300
C304 4822 126 11695 CER. CHIP 330pF ±5% CG 50V DD95331300
C331 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C332 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C333 4822 122 33777 CER. CHIP 47pF ±5% CG 50V DD95470300
C334 4822 122 33777 CER. CHIP 47pF ±5% CG 50V DD95470300
C335 4822 124 23649 ELECT. 470µF M 25V RA-2 OA47702520
C336 4822 124 23649 ELECT. 470µF M 25V RA-2 OA47702520
C337 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C338 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C339 4822 124 23649 ELECT. 470µF M 25V RA-2 OA47702520
C340 4822 124 23649 ELECT. 470µF M 25V RA-2 OA47702520
C341 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C342 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C343 MICA CHIP 1500pF ±5% DF95152040
C344 MICA CHIP 1500pF ±5% DF95152040
C345
4822 126 11663 CER. CHIP 12pF ±5% CG 50V DD95120300
C348
C351 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C352 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C353 4822 124 22693 ELECT. 10µF M 63V RA-2 OA10606320
C354
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C357
C358 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C359 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C401 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C402
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C405
C406 4822 124 22693 ELECT. 10µF M 63V RA-2 OA10606320
C407 4822 124 22693 ELECT. 10µF M 63V RA-2 OA10606320
C408 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C409
4822 124 22693 ELECT. 10µF M 63V RA-2 OA10606320
C412
C413 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C414 4822 126 11663 CER. CHIP 12pF ±5% CG 50V DD95120300
C415 4822 126 11663 CER. CHIP 12pF ±5% CG 50V DD95120300
C431 4822 124 90051 ELECT. 220µF M 25V ARA OA22702550
C432 4822 124 90051 ELECT. 220µF M 25V ARA OA22702550
C433
4822 124 41538 ELECT. 220µF M 35V RA-2 OA22703520
C436
C437 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C438 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C439 4822 126 12339 CER. CHIP 2200pF ±10% DK96222300
C440 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C441 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
C442 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
C443 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
C451
4822 124 23649 ELECT. 470µF M 25V RA-2 OA47702520
C454
C501 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C502 4822 122 33777 CER. CHIP 47pF ±5% CG 50V DD95470300
C503 4822 126 12339 CER. CHIP 2200pF ±10% DK96222300
C504 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C505 4822 126 11759 CER. CHIP 100pF ±5% CG 50V DD95101300
C506 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
C507 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C508 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C509 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C510 4822 122 33777 CER. CHIP 47pF ±5% CG 50V DD95470300
C511
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C516
C517 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C518
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C522
C611 ELECT. CAP 1000µF 35V OB10803510
C612 ELECT. CAP 1000µF35V OB10803510
C613 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C614 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C615 4822 124 90351 ELECT. 0.1µF M 50V RA-2 OA10405020
C616 4822 124 90351 ELECT. 0.1µF M 50V RA-2 OA10405020
C617 FILM 0.1µF ±5% DF15104350
C618 FILM 0.1µF ±5% DF15104350
C619 4822 124 22722 ELECT. 1000µF M 16V RA-2 OA10801620
C620 4822 124 22722 ELECT. 1000µF M 16V RA-2 OA10801620
C621 4822 124 90353 ELECT. 100µF H 10V RA-2 OA10701020
C622 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C623 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C624 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C625 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C626 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C627 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C651 4822 124 22243 ELECT. 6800µF 16V RA2 OA68801620
C652 4822 124 22243 ELECT. 6800µF 16V RA2 OA68801620
C653 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C654 FILM 0.1µF ±5% DF15104350
C655 4822 124 22722 ELECT. 1000µF M 16V RA-2 OA10801620
C656 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C657 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C658 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C659 BIG ELECT CAP 1F
EES5RV105
EX10500520
C660 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C661 4822 126 13303 CER. CHIP 1µF +80%-20% DK98105200
C662 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C663 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C664
4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C667
C671 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C672 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C681 4822 124 90355 ELECT. 100µF M 50V RA-2 OA10705020
C682 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C683 4822 124 22693 ELECT. 10µF 63V RA-2 OA10606320
C691 BIG ELECT CAP. 1F
EECS5RV105
EX10500520
