Marantz MD-19 - Page 30

34
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q652 4822 130 61541 CHIP TR. 2SC4116 HX341162B0
Q653 4822 130 61553 DIG.TRS. RN1303 BA21303000
Q654 4822 209 31925 IC PQ05RA1 1A 5V HC36905320
Q655 4822 209 33571 IC V-REGULATOR 3.3V
RN5RL33A
HC10012770
Q656 4822 209 17169 IC S-80720SN HC10087530
Q657 IC S-80735SN-DZ HC10055530
Q658 4822 209 33571 IC V-REGULATOR 3.3V
RN5RL33A
HC10012770
Q681 4822 209 73525 IC NJM 79L18A HC39118090
Q701 MICROPROCESSOR
MB90573 120PIN
HU362KF00F
Q702 4822 130 61553 DIG.TRS. RN1303 BA21303000
Q703 4822 130 61553 DIG.TRS. RN1303 BA21303000
Q704 4822 130 61553 DIG.TRS. RN1303 BA21303000
Q705 4822 209 91012 IC TC74HCT04 HC700405Q0
Q706 IC LC89170M HC10390030
Q707 4822 209 91012 IC TC74HCT04 HC700405Q0
Q901 4822 130 61554 CHIP TR. 2SA1586 HX115862B0
Q902 4822 130 61541 CHIP TR. 2SC4116 HX341162B0
Q903 4822 130 61541 CHIP TR. 2SC4116 HX341162B0
P406-MISCELLANEOUS
F301
FERRITE CORE FC90020120
F303 BK1608HM102-T
F401
FERRITE CORE FC90020120
F404 BK1608HM102-T
F431
FERRITE CORE FC90020120
F433 BK1608HM102-T
F501 FERRITE CORE
BK1608HM102-T
FC90020120
F502 4822 116 82487 CHIP 0Ω JUMPER NN05000610
F503
FERRITE CORE FC90020120
F505 BK1608HM102-T
F611 F FUSE 1A 250V UL CSA
MITI TYPE FBM
FS10100360
F611 K 4822 070 38001 FUSE 800 MA 250V BS LISTED FS10080850
F612 F FUSE 1A 250V UL CSA
MITI TYPE FBM
FS10100360
F612 K 4822 070 38001 FUSE 800 mA 250V BS LISTED FS10080850
F651 F FUSE 1A 250V UL CSA
MITI TYPE FBM
FS10100360
F651 K 4822 070 38001 FUSE 800 mA 250V BS LISTED FS10080850
F652 F FUSE 1A 250V UL CSA
MITI TYPE FBM
FS10100360
F652 K 4822 070 38001 FUSE 800 mA 250V BS LISTED FS10080850
J301 4822 290 81723 TERMINAL RCA PIN JACK 4P YT02041070
J501 4822 290 81638 TERMINAL RCA PIN JACK YT02010790
J502 4822 218 11487 OPTICAL RECIVER GP1F32R YJ15000150
J503 4822 218 11487 OPTICAL RECIVER GP1F32R YJ15000150
J504 4822 267 31369 OPTICAL OUTPUT GP1F32T YJ15000090
J505 4822 290 81638 TERMINAL RCA PIN JACK YT02010790
J701 JACK HLW19S-2C7 FPC
FCC CONN.19PIN
YJ07012790
J706 JACK HLW16S-2C7 FPC
FCC CONN.16PIN
YJ07012760
J711 4822 265 10221 JACK B10B-PH-K-S YJ06006300
J721 JACK HLW16S-2C7 FPC
FCC CONN.16PIN
YJ07012760
J901 4822 267 41009 TERMINAL 2P RCA PIN JACK YT02020890
L401 4822 157 53872 CHIP INDUCTANCE
NL322522-100k
LU12103010
L501 4822 142 60422 PULSE TRANSF. TP41042030
L502 4822 157 53872 CHIP INDUCTANCE
NL322522-100k
LU12103010
L611 4822 157 53872 CHIP INDUCTANCE
NL322522-100k
LU12103010
L612 4822 157 53872 CHIP INDUCTANCE
NL322522-100k
LU12103010
L651
CHIP INDUCTANCE LU83103020
L653 CR54-100 10µH
S651 4822 276 13185 PUSH SW. SP01011920
S901 4822 277 21712 SLIDE SW. SSSF 2-2 SS02021470
X401 4822 242 72395 CRYSTAL 11.2896MHz
AF5883CKA
JX11001260
X701 4822 242 72236 CRYSTAL 32.768KHz DT-38 XO001001T2
X702 4822 242 72066 SERAMIC VIB. CST8.0MT FQ08004010
P603-TRANS CIRCUIT BOARD
L601 F MAINS TRANSF. 57-35 EI 100V TS15745010
L601 K MAINS TRANSF. 57035 EI
115V/230V
TS15745020
P606-AC FILTER
CIRCUIT BOARD
P606-CAPACITORS
C601 F 4822 126 11237 CER. 0.01µF +80%-20% 250V
SPARK KILLER
DK18103850
C601 K 4822 122 33276 CER. 0.01µF ±20% DK17103840
P606-MISCELLANEOUS
F601 F FUSE 1A 250V UL CSA
MITI TYPE FBM
FS10100360
F601 K 4822 070 38001 FUSE 800 mA 250V BS LISTED FS10080850
L603 4822 157 70419 EMI LF-4D-102 FN01020020
S601 K 4822 277 21825 SLIDE SW.SDKGA4 SEMKO SS02021510
