Use the illustration below as a guide for how high each speaker should be
installed. The height does not need to be exactly the same.
.
GViewed from the sideH
Front speaker
Surround speaker
60 – 90 cm
o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z1 22° - 30° z2 120°
