Connecting multi-zone speakers
o
5.1-channel (MAIN ZONE) + 2-channel (ZONE2) speaker connection
This connection method constructs a 5.1-channel speaker system in the MAIN ZONE and a 2-channel system in ZONE2.
MAIN ZONE
.
FL
SW C
SL
FR
SR
ZONE2
.
ZONE2
L
ZONE2
R
.
CSRSL
SW
ZONE2
R
ZONE2
L
FLFR
0
Set “Assign Mode” to “ZONE2” in the menu. (v p. 188)
