Marantz PMD330 - Page 20

34
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P101-SERVO CIRCUIT BOARD
P101-CAPACITORS
C101 331/340 4822 126 11669 CER. CHIP 27pF ±5% DD95270300
C102 331/340 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C103 4822 126 11669 CER. CHIP 27pF ±5% DD95270300
C104 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C105 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C106 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C107 4822 122 31765 CER. CHIP 100pF ±5% CG 50V DD95101300
C108 4822 122 31765 CER. CHIP 100pF ±5% CG50V DD95101300
C109 4822 126 14417 CER. CHIP 0.01µF ±10% 50V DK96103300
C110 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
C111 ELECT 100µF 10V EJ10701010
C112 ELECT 100µF 10V EJ10701010
C113 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C114 ELECT 47µF 10V EJ47601010
C115 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C116 330/331 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C117 330/331 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C118 4822 122 31765 CER. CHIP 100pF ±5% CG 50V DD95101300
C119 330 CER. CHIP 2pF ±0.25pF CK DD90020300
C120 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
C201 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C202 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C203 ELECT 100µF 10V EJ10701010
C204 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C205 4822 126 11685 CER. CHIP 4700P ±10% 50V DK96472300
C206 330/331 4822 126 11685 CER. CHIP 4700P ±10% 50V DK96472300
C207 ELECT 100µF 10V EJ10701010
C208 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C209 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C210 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C211 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C212 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C213 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C214 CER. CHIP 0.22µF ±10% B 16V DK56224200
C215 330/331 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C216 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
C217 CER. CHIP 0.47µF ±10% 16V B DK56474200
C218 331 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C251 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C252 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C253 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C254 340 ELECT 100µF 10V EJ10701010
C255 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C256 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C257 340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C258 340 4822 126 13396 CER. CHIP 0.047µF ±10% 16V DK96473200
P101-RESISTORS
R101 4822 051 30681 CHIP 680Ω ±5% 1/16W NN05681610
R102 4822 051 30681 CHIP 680Ω ±5% 1/16W NN05681610
R103 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R104 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R105 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R106 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
R107 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R108 4822 051 30152 CHIP 1.5kΩ ±5% 1/16W NN05152610
R109 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
R110 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R111 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
R112 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
R113 4822 051 30562 CHIP 5.6kΩ ±5% 1/16W NN05562610
R114 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R116 4822 117 12891 CHIP 220kΩ ±5% 1/16W NN05224610
R117 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R118 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R121 4822 117 13632 CHIP 100kΩ ±5% 1/16W NN05104610
R123 4822 117 13632 CHIP 100kΩ ±5% 1/16W NN05104610
R124 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R125 4822 117 12902 CHIP 8.2kΩ ±5% 1/16W NN05822610
R126
330/331 4822 051 30332 CHIP 3.3kΩ ±5% 1/16W NN05332610
R130
R131 330/331 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R133 330/331 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R134 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R135 4822 117 12902 CHIP 8.2kΩ ±5% 1/16W NN05822610
R137 330/331 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R201 4822 051 30683 CHIP 68kΩ ±5% 1/16W NN05683610
R202 4822 051 30683 CHIP 68kΩ ±5% 1/16W NN05683610
R203 4822 051 30272 CHIP 2.7kΩ ±5% 1/16W NN05272610
R204 4822 051 30184 CHIP 180kΩ ±5% 1/16W NN05184610
R205 4822 051 30184 CHIP 180kΩ ±5% 1/16W NN05184610
R206 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
R207 4822 117 12891 CHIP 220kΩ ±5% 1/16W NN05224610
R208 4822 117 12891 CHIP 220kΩ ±5% 1/16W NN05224610
R209 4822 116 83819 CHIP 18kΩ ±5% 1/16W NN05183610
R210 330/331 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R211 330/331 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R212 330/331 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
R213 330/331 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R214 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R215 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
R216 4822 051 30123 CHIP 12kΩ ±5% 1/16W NN05123610
R217 331/340 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
R251 340 CHIP 82Ω ±5% 1/10W NI05820110
R252 340 CHIP 82Ω ±5% 1/10W NI05820110
R253 340 4822 051 30682 CHIP 6.8kΩ ±5% 1/16W NN05682610
R254 340 4822 051 30682 CHIP 6.8kΩ ±5% 1/16W NN05682610
R255 340 4822 051 30682 CHIP 6.8kΩ ±5% 1/16W NN05682610
R256 340 4822 117 13632 CHIP 100kΩ ±5% 1/16W NN05104610
R257 340 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R258 340 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R259 340 CHIP 2.2Ω ±5% 1/10W NI05022110
R260 340 CHIP 2.2Ω ±5% 1/10W NI05022110
R261 340 CHIP 2.2Ω ±5% 1/10W NI05022110
R262 340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R263 340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R264 340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R265 340 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R266 340 CHIP 2.2Ω ±5% 1/10W NI05022110
P101-SEMICONDUCTORS
Q101 330/331 9965 000 01600 IC TZA1022 HF AMP/LA CONT HC10180490
Q102 9965 000 01720 IC NJM2137M-TE1 DUAL OP HC10206090
Q103 4822 209 30455 IC NJM2100M JRC HC10085090
Q104 4822 130 61906 DIG.TRS. DTC114EU BA20035210
Q105 4822 130 61906 DIG.TRS. DTC114EU BA20035210
Q106 4822 130 60731 CHIP TRS. 2SA1036K Q R HX110362B0
Q107 4822 130 61906 DIG.TRS. DTC114EU BA20035210
Q108 4822 130 11357 DIG.TRS. RN2307 DTA114YU BA12307000
Q109 9965 000 01601 THERMISTOR
TN10-4C103JT 10k
HH50005780
Q110 331/340 4822 130 61906 DIG.TRS. DTC114EU BA20035210
Q112 340 9965 000 01601 THERMISTOR
TN10-4C103JT 10k
HH50005780
Q201 4822 209 16372 IC TDA7073AT
SOP DUAL BTL DRIVER
HC10165490
Q202 4822 209 16372 IC TDA7073AT
SOP DUAL BTL DRIVER
HC10165490
Q203 331/340 9965 000 01601 THERMISTOR
TN10-4C103JT 10k
HH50005780
Q251 340 4822 209 16877 IC BA6856FP
3PH-MOTOR DRIVER
HC10213210
Q252 340 4822 130 60731 CHIP TRS. 2SA1036K Q R HX110362B0
