35
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P101-MISCELLANEOUS
J101 JACK 16FMZ-ST FFC CONN. YJ07020820
J102 JACK 20FE-ST-VK-N 20PIN YJ07020160
J202 JACK 11FM-1.0ST FFC CONN. YJ07020830
P801-TRANS CIRCUIT BOARD
L801 /F, /U MAINS TRANSF. EI-57
100V/120V
TS15747010
L801 /N 9965 000 01599 MAINS TRANSF. EI-57 230V TS15747020
P851-POWER SW
CIRCUIT BOARD
C851 4822 122 33276 CER. DE7150 F 103M VA1 KC DK17103840
L851 4822 157 70419 LF-4D-102 FN01020020
S851 4822 276 13364 PUSH SWITCH SDDLD1
POWER TV-3
SP01011990
PB01-XLR CONN. CIRCUIT
BOARD [PMD331/340]
PB01-CAPACITORS
CT52 331/340 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CT53 331/340 CER. 50V DC 0.1µF +80 -20% DD38104010
CT56 331/340 CER. 0.01µF ±10% 50V DK16103300
CT57 331/340 CER. 0.01µF ±10% 50V DK16103300
CT58 331/340 CER. 220pF ±10% 50V DK16221300
CT59 331/340 CER. 220pF ±10% 50V DK16221300
PB01-RESISTORS
RT52 331/340 56Ω ±5% 1/6W GG05560160
RT53 331/340 56Ω ±5% 1/6W GG05560160
PB01-SEMICONDUCTOR
QT52 331/340 5322 209 60473 IC SN75158/P TEXAS INST. HC10071370
PB01-MISCELLANEOUS
JB53 331/340 JACK NC3MAH 3P CANNON YJ01004070
JB54 331/340 JACK NC3MAH 3P CANNON YJ01004070
JT53 331/340 JACK NC3MAH 3P CANNON YJ01004070
LT52 331/340 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LT53 331/340 4822 148 81381 PULSE TRANSF. TC-1086-26 TP33842010
LT54 331/340 FERRITE CORE
BL02RN1-R62T2
FC90050040
LT55 331/340 FERRITE CORE
BL02RN1-R62T2
FC90050040
PD01-MAIN CIRCUIT BOARD
PD01-CAPACITORS
CB01 331/340 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CB02
331/340 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
CB06
CB07
331/340 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CB13
CB14
331/340 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
CB21
CD01 330/331 4822 126 11685 CER. CHIP 4700pF ±10% B 50V DK96472300
CD01 340 4822 126 CER. CHIP 3300pF ±10% B 50V DK96332300
CD02 4822 126 13396 CER. CHIP 0.047µF ±10% X7R DK96473200
CD03 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CD04 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CD05 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
CD06 CER. CHIP 0.47µF ±10% 16V B DK56474200
CD07 4822 126 13396 CER. CHIP 0.047µF ±10% X7R DK96473200
CD08 4822 126 12495 CER. CHIP 1500P ±10% 50V DK96152300
CD09 5322 126 11578 CER. CHIP 1000P ±10% 50V DK96102300
CD10 9965 000 00599 CER. CHIP 0.22µF ±10% B 10V DK96224200
CD11 9965 000 00599 CER. CHIP 0.22µF ±10% B 10V DK96224200
CD12 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CD13 4822 122 32672 TANTL.CHIP 1µF 16V EY10501610
CD14 5322 124 41744 ELECT. 4700µF 10V RA-2 OA47801020
CD15 4822 126 13689 CER. CHIP 18pF ±5% DD95180300
CD16 4822 122 33752 CER. CHIP 15pF ±5% CG 50V DD95150300
CD17 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CD18 4822 126 13396 CER. CHIP 0.047µF ±10% X7R DK96473200
CD19 330 4822 126 11671 CER. CHIP 33pF ±5% CG 50V DD95330300
CD19 331/340 5322 126 14449 CER. CHIP 39pF ±5% CG 50V DD95390300
CD20 4822 122 33753 CER. CHIP 150pF ±5% CG 50V DD95151300
CD21 330 4822 126 13689 CER. CHIP 18pF ±5% CG 50V DD95180300
CD22 331/340 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CD23 331/340 4822 122 31765 CER. CHIP 100pF ±5% CG 50V DD95101300
CM01 5322 122 32654 CER. CHIP 0.022µF ±10% 16V DK96223200
CT01 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CT03 4822 126 12339 CER. CHIP 2200P ±10% 50V DK96222300
CT04 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CT07 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CT08 331/340 4822 124 22275 ELECT. 47µF M 10V RA-2 OA47601020
CU01 4822 122 33752 CER. CHIP 15pF ±5% CG 50V DD95150300
CU02 4822 122 33752 CER. CHIP 15pF ±5% CG 50V DD95150300
CU03 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CU04 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CU05 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CU41 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CU51 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
CU53 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CU54 331/340 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CU60
331/340 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CU79
CU80 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
CU91 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C301 331/340 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C302 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C303 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C304 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C305 331/340 4822 126 13396 CER. CHIP 0.047µF ±10% X7R DK96473200
C501 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C502 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C503 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
C504 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
C505 4822 122 33753 CER. CHIP 150pF ±5% 50V DD95151300
C506 4822 122 33753 CER. CHIP 150pF ±5% 50V DD95151300
C507 4822 122 33753 CER. CHIP 150pF ±5% 50V DD95151300
C508 4822 122 33753 CER. CHIP 150pF ±5% 50V DD95151300
C509 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C510 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C511 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C512 5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
C513 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C514 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C515 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C516 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C517 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C518
4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C522
C523 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C524 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C525 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C526 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
C541 331/340 4822 126 13837 CER. CHIP 0.1µF ±10% B 10V DK96104200
