Marantz PMD330 - Page 22

36
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C801 330 4822 124 22243 ELECT 6800µF 16V RE3 OA68801620
C801 331/340 ELECT 10000µF 16V RE3 EA10901670
C802 CER. 0.1µF +80%-20% 50V DD38104010
C803 CER. 0.1µF +80%-20% 50V DD38104010
C804 4822 124 90371 ELECT. 470µF M 10V RA-2 OA47701020
C805 CER. 0.1µF +80%-20% 50V DD38104010
C806 CER. 0.1µF +80%-20% 50V DD38104010
C807 4822 124 90371 ELECT. 470µF M 10V RA-2 OA47701020
C808 4822 124 11583 ELECT. 2200µF M 35V RA-2 OA22803520
C809 4822 124 11583 ELECT. 2200µF M 35V RA-2 OA22803520
C810 CER. 0.1µF +80%-20% 50V DD38104010
C811 CER. 0.1µF +80%-20% 50V DD38104010
C812 CER. 0.1µF +80%-20% 50V DD38104010
C813 CER. 0.1µF +80%-20% 50V DD38104010
C814 4822 124 22277 ELECT. 470µF 16V M RA-2 OA47701620
C815 4822 124 22277 ELECT. 470µF 16V M RA-2 OA47701620
C816 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
PD01-RESISTORS
RB01 331/340 9965 000 01716 VARIABLE 10kΩ B RK01031580
RB02 331/340 9965 000 01716 VARIABLE 10kΩ B RK01031580
RB03 331/340 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
RB04 331/340 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
RB05 331/340 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RB06 331/340 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RB07 331/340 4822 051 30682 CHIP 6.8kΩ ±5% 1/16W NN05682610
RB08 331/340 4822 051 30682 CHIP 6.8kΩ ±5% 1/16W NN05682610
RB09 331/340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RB10 331/340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RB11 331/340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RB12 331/340 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RB13
331/340 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RB24
RB25
331/340 4822 051 30479 CHIP 47Ω ±5% 1/16W NN05470610
RB28
RB29
331/340 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RB32
RB33
331/340 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RB36
RD01 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
RD02 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
RD03 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
RD04 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RD05 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD06 4822 117 13632 CHIP 100kΩ ±5% 1/16W NN05104610
RD07 4822 051 30332 CHIP 3.3kΩ ±5% 1/16W NN05332610
RD08 4822 051 30332 CHIP 3.3kΩ ±5% 1/16W NN05332610
RD09 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD10 4822 051 30105 CHIP 1MΩ ±5% 1/16W NN05105610
RD11 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RD12 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
RD13 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
RD15 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RD16 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD17 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD18 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD19 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RD20 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
RD22 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
RD23 331 4822 116 83819 CHIP 18kΩ ±5% 1/16W NN05183610
RD23 340 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
RM01 4822 111 90967 FUSE 4.7Ω J 1/4W NF05047140
RM02 4822 051 30681 CHIP 680Ω ±5% 1/16W NN05681610
RT02 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
RT03 4822 051 30331 CHIP 330Ω ±5% 1/16W NN05331610
RT04 4822 051 30759 CHIP 75Ω ±5% 1/16W NN05750610
RU01 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU02 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU04 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU05 330/331 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
RU06 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU07 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU08 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU09 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU10 330/340 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
RU11
4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU21
RU22 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU23
4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU27
RU28 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU30 4822 051 30105 CHIP 1MΩ ±5% 1/16W NN05105610
RU31 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU32 330 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU41 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RU42 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RU51 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
RU52 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
RU53 4822 116 83819 CHIP 18kΩ ±5% 1/16W NN05183610
RU54 4822 051 30479 CHIP 47Ω ±5% 1/16W NN05470610
RU55 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
RU58 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RU60 331/340 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
RU62
331/340 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
RU74
RU80
331/340 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
RU90
RU91 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU92 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
RU93 331/340 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
RU94 331/340 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
RU95 331/340 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R301 331/340 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
R501 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R502 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R503 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
R504 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
R505 4822 116 83819 CHIP 18kΩ ±5% 1/16W NN05183610
R506 4822 116 83819 CHIP 18kΩ ±5% 1/16W NN05183610
R507 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
R508 4822 051 30333 CHIP 33kΩ ±5% 1/16W NN05333610
R509 4822 051 30123 CHIP 12kΩ ±5% 1/16W NN05123610
R510 4822 051 30123 CHIP 12kΩ ±5% 1/16W NN05123610
R511 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R512 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R513 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R514 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R515 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R516 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R517 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R518 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R519 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R520 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R531 330 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R532 330 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R533 330 4822 116 82487 CHIP 0Ω ±5% 1/16W NN05000610
R541 331/340 4822 117 13632 CHIP 100kΩ ±5% 1/16W NN05104610
R542 331/340 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
