37
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R543 331/340 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R544 331/340 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R801
4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
R805
PD01-SEMICONDUCTORS
DB01 331/340 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DB02 331/340 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DM02 9965 000 01598 CHIP DIODE
UDZS8.2B MA8082-M
HZ30821000
DU01 9965 000 01491 CHIP DIODE DA227
ARRAY 2PIECES-2125
HZ20032210
DU02 9965 000 01491 CHIP DIODE DA227
ARRAY 2PIECES-2125
HZ20032210
DU03 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DU51 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DU52 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
D501 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
D502 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D801 4822 130 83067 DIODE D3SB 20
V=200V IO=3.0A
HE20020290
D802 4822 130 10413 DIODE BRIDGE D2SBA20 HE20027290
D803 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
QB01
331/340 4822 209 83357 IC NJM4560M JRC HC10029090
QB04
QD01 9965 000 01437 IC CXD2585Q CD DECODER HC10069250
QD02 331/340 9965 000 01601 THERMISTOR
TN10-4C103JT 10k
HH50005780
QM01 4822 209 30193 IC LB1641 MOTOR DRIVER
HC10279030
QU01 9965 000 01492 MICROPROCESSOR
HD643306ZF MPU
HU371KH00F
QU03 9965 000 01595 IC AT25640
64K EEPROM
HC10074990
QU04 9965 000 01596 IC 74HC4094BT FLAT HC809449R0
QU41 4822 130 60731 CHIP TRS. 2SA1036K Q R HX110362B0
QU42 4822 130 61906 DIG.TRS. DTC114EU BA20035210
QU51 4822 130 60669 CHIP TRS. 2SC4081 Q R
2SC4116 Y GR
HX300012A0
QU52 4822 130 61906 DIG.TRS. DTC114EU BA20035210
QU53 4822 130 11357 DIG.TRS. RN2307 DTA114YU BA12307000
QU55 4822 130 11357 DIG.TRS. RN2307 DTA114YU BA12307000
QU56 9965 000 01596 IC 74HC4094BT FLAT HC809449R0
QU57 4822 209 17428 IC 74HC165F HC716500R0
QU58 4822 209 17428 IC 74HC165F HC716500R0
QU59
4822 130 61906 DIG.TRS. DTC114EU BA20035210
QU64
QU91 4822 209 30426 IC CMOS 74HC00 FLAT HC700000Z0
Q301 331/340 9965 000 01717 IC RL5C357 SHOCK PROOF HC10042770
Q302 331/340 9965 000 01718 IC HY5117400BJ-60 DRAM HC10089990
Q501 4822 209 15226 IC PCM1710U 16/20BIT DAC HC10004610
Q502 4822 209 83357 IC NJM4560 FLAT PACK JRC HC10029090
Q541 331/340 4822 130 11357 DIG.TRS. RN2307 DTA114YU BA12307000
Q542 331/340 4822 130 43818 TRS. 2SC2878 A OR B HT328782A0
Q543 331/340 4822 130 43818 TRS. 2SC2878 A OR B HT328782A0
Q801 4822 209 83824 IC NJM7805FA +5V 1A JRC HC38905090
Q802 4822 209 73674 IC NJM7806FA +6V 1A JRC HC38906090
Q803 4822 209 82829 IC NJM78M15FA +15V 0.5A HC38515090
Q804 4822 209 83828 IC NJM79M15FA -15V 0.5A HC39515090
Q805 4822 130 61906 DIG.TRS. DTC114EU BA20035210
Q806 4822 130 61906 DIG.TRS. DTC114EU BA20035210
PD01-MISCELLANEOUS
JD01 JACK 20FE-BT-VK-N 20PIN YJ07020530
JT01 4822 267 31729 TERMINAL 14X14 RA 1L1P BLK YT02010780
OPTICAL OUTPUT
YJ15000090
JU01 JACK 30PIN 30FMN-BMTTR-TB YJ07016500
JU51 TERMINAL RCA JACK ORG YT02021090
JU53 331/340 4822 265 11401 PLUG D-SUB 25P FEMALE YP11000180
J501 4822 267 31727 TERMINAL 14X14 RCA 2L2P YT02021210
LB01 331/340 9965 000 01343 RELAY RELAY MR62-12SR LY20120510
LB02 331/340 9965 000 01343 RELAY RELAY MR62-12SR LY20120510
LD01 CHIP INDUCTANCE
4.7µH ±10% 1608 TYPE
LU04472010
LD02 CHIP INDUCTANCE
4.7µH ±10% 1608 TYPE
LU04472010
LD03 CHIP INDUCTANCE
0.47µH ±10% MLF1608
LU04471010
LD04 CHIP INDUCTANCE
0.47µH ±10% MLF1608
LU04471010
LT01 4822 142 60388 PULSE TRANSF. FOR CD TP41042010
LT02 FERRIT BEADS
BK1608HM102-T
FC90020120
LT03 331/340 FERRIT BEADS
BK1608HM102-T
FC90020120
L501 9965 000 01343 RELAY MR62-12SR LY20120510
SU51 4822 277 21789 SLIDE SWITCH SSSUI-6MM SS02020970
XD01 4822 242 10883 CRYSTAL CM309S
16.9344MHz CITIZEN
JX16002360
XU01 9965 000 01597 CRYSTAL CM309S 20MHz JX20001360
PV01-HEAD PHONE
CIRCUIT BOARD
PV01-CAPACITORS
CV01 ELECT 100µF 16V RC-2 EJ10701610
CV02 ELECT 100µF 16V RC-2 EJ10701610
CV03 ELECT 47µF 16V EJ47601610
CV04 ELECT 47µF 16V EJ47601610
PV01-RESISTORS
RV01 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
RV02 4822 051 30153 CHIP 15kΩ ±5% 1/16W NN05153610
RV03 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RV04 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RV05 9965 000 01489 CHIP 120Ω ±5% 1/2W RI05121120
RV06 9965 000 01489 CHIP 120Ω ±5% 1/2W RI05121120
RV07 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RV08 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
RV09 9965 000 01490 VARIABLE 50kΩ A L=15MM RM05033070
PV01-SEMICONDUCTOR
QV01 4822 209 31378 IC NJM4556AM JRC HC10045090
PV01-MISCELLANEOU
JV02 4822 267 31126 JACK ST HEADPHONE BL/GL YJ01003020
PY01-DISPLAY
CIRCUIT BOARD
PY01-CAPACITORS
CY01 9965 000 01438 TANTL.CHIP 2.2µF 50V EY22505020
CY02 9965 000 01438 TANTL.CHIP 2.2µF 50V EY22505020
CY03 9965 000 01438 TANTL.CHIP 2.2µF 50V EY22505020
CY04 4822 124 23002 TANTL.CHIP 10µF 16V EY10601620
CY05 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
CY06 4822 124 11226 TANTL.CHIP 22µF 6.3V EY22600620
CY07 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
CY08 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
CY09 4822 126 14417 CER. CHIP 0.01µF ±10% 50V K DK96103300
JT02 331/340 4822 267 31369 OPT. CONN.GP1F32T
