Marantz PMD330 - Page 24

38
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CY10
5322 126 11578 CER. CHIP 1000pF ±10% B DK96102300
CY17
PY01-RESISTORS
RY01 9965 000 01444 VARIABLE 100kΩ B W/CLIC RB01040080
RY02 4822 051 30332 CHIP 3.3kΩ ±5% 1/16W NN05332610
RY03 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RY04 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RY05 4822 051 30273 CHIP 27kΩ ±5% 1/16W NN05273610
RY06 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RY07 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
RY08 4822 117 12864 CHIP 82kΩ ±5% 1/16W NN05823610
RY09 4822 051 30101 CHIP 100Ω ±5% 1/16W NN05101610
RY11 4822 051 30101 CHIP 100Ω ±5% 1/16W NN05101610
RY12 4822 051 30101 CHIP 100Ω ±5% 1/16W NN05101610
RY13 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
RY14 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
RY15 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
RY16 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
RY17 4822 051 30101 CHIP 100Ω ±5% 1/16W NN05101610
RY18 4822 117 12891 CHIP 220kΩ ±5% 1/16W NN05224610
RY19 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
RY20 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
PY01-SEMICONDUCTORS
DY01
9965 000 01439 L.E.D. FY1101F-TX HI10010300
DY06 YELLOW CHIP
DY07 9965 000 01440 L.E.D. SML-310DT
ORANGE CHIP
HI10103210
DY08 9965 000 01440 L.E.D. SML-310DT
ORANGE CHIP
HI10103210
DY09
9965 000 01441 L.E.D. SML-310MT HI10104210
DY12 GREEN CHIP
DY13
9965 000 01440 L.E.D. SML-310DT HI10103210
DY18 ORANGE CHIP
QY01 9965 000 01442 IC HD66712SA02FS LCD DRIV. HC10132010
QY02 4822 130 60669 CHIP TRS. 2SC4081 Q R
2SC4116 Y GR
HX300012A0
QY05 9965 000 01443 DISPLAY UNIT LCD HQ22801800
QY06 4822 130 61906 DIG.TRS. DTC114EU BA20035210
QY07 4822 130 61906 DIG.TRS. DTC114EU BA20035210
QY08 4822 130 61906 DIG.TRS. DTC114EU BA20035210
QY09 4822 130 61906 DIG.TRS. DTC114EU BA20035210
PY01MISCELLANEOUS
JY01 JACK 30PIN 30FMN-BMTTR-TB YJ07016500
JY03 JUMPER LEAD ZEBRA CONN. YU01009700
SY14
9965 000 01445 TACT SWITCH SKHMPW SP01013320
SY28
PY41-IR SENSOR
CIRCUIT BOARD
QY41 4822 130 10161 PHOTO UNIT SPS-446-4
IR SENSOR SANYO
HW10005030
PY51-PITCH DIAL CIRCUIT
BOARD FOR PMD331/340
SY51 331/340 9965 000 01719 ROTARY SWITCH
EC16B2410207 L=20 HOL
SR01240020
