NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
001B /F1B nsp 49AS248010 FRONT PANEL FRONT PANEL BLACK
001B /F1S nsp 49AS248020 FRONT PANEL FRONT PANEL SILVER
001B /N1B 49AS248010 49AS248010 FRONT PANEL FRONT PANEL BLACK
001B /N1S 49AS248020 49AS248020 FRONT PANEL FRONT PANEL SILVER
001B /U1B nsp 49AS248010 FRONT PANEL FRONT PANEL BLACK
001B /U1S nsp 49AS248020 FRONT PANEL FRONT PANEL SILVER
003B 49AS259010 49AS259010 BUSHING POWER BUTTON BUSH
004B 238H355020 238H355020 LENS LENS
008B 49AS259020 49AS259020 BUSHING BUTTON BUSH A(6PIECE)
010B 49AS158010 49AS158010 WINDOW WINDOW
013B 49AS280500 49AS280500 HOUSING CF HOUSING ASSY
016B
/F1B nsp 04AS162010 DOOR CF CARD DOOR BLACK
016B /F1S nsp 04AS162110 DOOR CF CARD DOOR SILVER
016B /N1B 04AS162010 04AS162010 DOOR CF CARD DOOR BLACK
016B /N1S 04AS162110 04AS162110 DOOR CF CARD DOOR SILVER
016B /U1B nsp 04AS162010 DOOR CF CARD DOOR BLACK
016B /U1S nsp 04AS162110 DOOR CF CARD DOOR SILVER
017B 2912259020 2912259020 BUSHING DOOR BUSH
018B 49AS112010 49AS112010 SHAFT DOOR SHAFT
022B 49AS270010 49AS270010 BUTTON TACT KEY
024B 49AS270110 49AS270110 BUTTON PLAY BUTTON
026B 49AS270210 49AS270210 BUTTON STOP BUTTON
028B 49AS270310 49AS270310 BUTTON REC BUTTON
033B 409S355300 409S355300 LENS LCD LENS
044B
/F1B nsp 284T154310 KNOB H.P VOL. KNOB BLACK
044B /F1S nsp 284T154350 KNOB H.P VOL. KNOB SILVER
044B /N1B 284T154310 284T154310 KNOB H.P VOL. KNOB BLACK
044B /N1S 284T154350 284T154350 KNOB H.P VOL. KNOB SILVER
044B /U1B nsp 284T154310 KNOB H.P VOL. KNOB BLACK
044B /U1S nsp 284T154350 KNOB H.P VOL. KNOB
048B 388K154120 388K154120 KNOB JOG
050B
/F1S nsp 02AS010010 SCREW HEXA SOCKET HEAD SCREW SIL
050B /N1S 02AS010010 02AS010010 SCREW HEXA SOCKET HEAD SCREW SIL
050B /U1S nsp 02AS010010 SCREW HEXA SOCKET HEAD SCREW SIL
004G 416H057010 416H057010 LEG LEG
008G /F1B nsp 023J270020 BUTTON POWER BUTTON BLACK
008G
/F1S nsp 023J270120 BUTTON POWER BUTTON SILVER
008G /N1B 023J270020 023J270020 BUTTON POWER BUTTON BLACK
008G
/N1S 023J270120 023J270120 BUTTON POWER BUTTON SILVER
008G /U1B nsp 023J270020 BUTTON POWER BUTTON BLACK
008G
/U1S nsp 023J270120 BUTTON POWER BUTTON SILVER
010G 416T121010 416T121010 LINK LINK
J092
/F1B nsp YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
J092 /F1S nsp YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
J092
/N1B YJ04002450 YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
J092 /N1S YJ04002450 YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
J092 /U1B nsp YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
J092 /U1S nsp YJ04002450 JACK ! 3P MAINS INLET M1910-D EMUDEN
WA13 nsp YU25110520 JUMPER LEAD JU08-JF01 MAIN-LCD PCB
WA14 nsp YU19190520 JUMPER LEAD JU06-JU09 MAIN-REAR(PA01)
PACKING
001T
/F1B nsp 49AS851110 USER GUIDE USER GUIDE JAPANESE
001T /F1S nsp 49AS851110 USER GUIDE USER GUIDE JAPANESE
001T /N1B 49AS851250 49AS851250 USER GUIDE USER GUIDE U,N 4LANGUAGE
001T /N1S 49AS851250 49AS851250 USER GUIDE USER GUIDE U,N 4LANGUAGE
001T /U1B nsp 49AS851250 USER GUIDE USER GUIDE U,N 4LANGUAGE
001T /U1S nsp 49AS851250 USER GUIDE USER GUIDE U,N 4LANGUAGE
002T /N1B 49AS851020 49AS851020 USER GUIDE CD-ROM USER GUIDE
002T /N1S 49AS851020 49AS851020 USER GUIDE CD-ROM USER GUIDE
002T
/U1B nsp 49AS851020 USER GUIDE CD-ROM USER GUIDE
002T /U1S nsp 49AS851020 USER GUIDE CD-ROM USER GUIDE
W001
/F1B nsp ZC01801070 MAINS CORD ! MAINS POWER CABLE 125V 7A
W001 /F1S nsp ZC01801070 MAINS CORD ! MAINS POWER CABLE 125V 7A
W001
/N1B ZC02003190 ZC02003190 MAINS CORD # MAINS CORD 3P FOR N 10A 250V AC
W001 /N1S ZC02003190 ZC02003190 MAINS CORD # MAINS CORD 3P FOR N 10A 250V AC
W001
/U1B nsp ZC02002180 MAINS CORD # MAINS CORD 3P 10A 125V NM U KAW
W001 /U1S nsp ZC02002180 MAINS CORD # MAINS CORD 3P 10A 125V NM U KAW
017Z 2912259020 2912259020 BUSHING DOOR HOLE BUSH
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P.C.B.
NAME
POS. NO.
