Marantz PMD570 Service Manual

78
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P.C.B.
NAME
POS. NO.
PF01 RF03 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PF01 RF04 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PF01 RF05 nsp NN05151610 CHIP RESISTOR 150 OHM +- 5% 1/16W
PF01 RF10 nsp NN05151610 CHIP RESISTOR 150 OHM +- 5% 1/16W
PF01 RF11 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PF01 RF12 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PF01 SF01 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 SF02 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 SF03 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 SF04 SP01013960 SP01013960 PUSH SWITCH SKECFKA010 (RED)
PF01 SF05 SP01013970 SP01013970 PUSH SWITCH SKECFLA010 (PURE GREEN)
PF01 SF06 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 SF07 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 SF08 SP01013950 SP01013950 PUSH SWITCH SKECAFA010
PF01 VF01 HQ21902980 HQ21902980 DISPLAY UNIT LCD STN 1/18DUTY 1/5BIAS
PF91 DF91 HI10042080 HI10042080 L.E.D. SECU1E01C
PF91 RF91 nsp NN05471610 CHIP RESISTOR 470 OHM +- 5% 1/16W
PM01 C321 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C322 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C340 EA47701010 EA47701010 ELECT CAP. 470µF/ 10V
PM01 C341 nsp DD95330300 CERAMIC CAP. 33 PF +- 5% CG 50V
PM01 C342 nsp DD95330300 CERAMIC CAP. 33 PF +- 5% CG 50V
PM01 C343 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C344 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C345 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PM01 C346 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PM01 C347 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C348 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C351 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C352 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C353 nsp DD95220300 CERAMIC CAP. 22 PF +- 5% CG 50V GR39
PM01 C354 nsp DD95220300 CERAMIC CAP. 22 PF +- 5% CG 50V GR39
PM01 C355 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PM01 C401 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C402 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PM01 C403 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PM01 C404 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PM01 C405 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PM01 C406 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C407 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C408 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C409 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C410 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C412 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C413 nsp DK98105200 CERAMIC CAP. 1µF 10V F
PM01 C414 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C415 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C416 nsp DK96474200 CERAMIC CAP. 0.47µF/10V B(BJ) +-10%
PM01 C417 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C418 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C419 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C420 EY10601070 EY10601070 TANTL.CAP CHIP 10µF/ 10V
PM01 C421 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C422 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C423 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C424 EY10601070 EY10601070 TANTL.CAP CHIP 10µF/ 10V
PM01 C425 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C426 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C427 EY10601070 EY10601070 TANTL.CAP CHIP 10µF/ 10V
PM01 C428 EY10601070 EY10601070 TANTL.CAP CHIP 10µF/ 10V
PM01 C429 EY10601070 EY10601070 TANTL.CAP CHIP 10µF/ 10V
PM01 C430 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C431 EY10601670 EY10601670 TANTL.CAP CHIP MSVB21C 10µF/16V
PM01 C801 EA47702510 EA47702510 ELECT CAP. 470µF/ 25V
PM01 C802 EY47601620 EY47601620 TANTL.CAP CHIP 47µF/ 16V
PM01 C803 EY47701020 EY47701020 TANTL.CAP CHIP 470µF/ 10V
PM01 C804 EY10701020 EY10701020 TANTL.CAP CHIP 100µF/ 10V
PM01 C805 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PM01 C806 EY10701620 EY10701620 TANTL.CAP CHIP 100µF/ 16V
PM01 C807 EY10601620 EY10601620 TANTL.CAP CHIP 10µF/ 16V
