Marantz PMD570 Service Manual

77
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P.C.B.
NAME
POS. NO.
PC01 CC09 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PC01 CC10 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PC01 CC11 nsp OA22701620 ELECT. CAP. 220 µF M 16V RA-2
PC01 CC12 nsp OA22701620 ELECT. CAP. 220 µF M 16V RA-2
PC01 CC13 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PC01 CC14 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PC01 CC15 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PC01 CC16 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PC01 CC21 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PC01 CC22 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PC01 JC02 YJ01003280 YJ01003280 JACK YKB21-5009 6.3MM ST PHONE JACK
PC01 LC01 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PC01 LC02 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PC01 LC03 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PC01 LC04 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PC01 LC21 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PC01 QC01 HC10045090 HC10045090 IC NJM-4556MB
PC01 QC03 BA20080210 BA20080210 SEMICON.COMP DTC323TU
PC01 QC04 BA20080210 BA20080210 SEMICON.COMP DTC323TU
PC01 QC05 BA20080210 BA20080210 SEMICON.COMP DTC323TU
PC01 QC06 BA20080210 BA20080210 SEMICON.COMP DTC323TU
PC01 RC01 RM01031250 RM01031250 VARIABLE RESIST RK0971220 10K A (D-CUT REV)
PC01 RC03 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PC01 RC04 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PC01 RC05 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PC01 RC06 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PC01 RC07 nsp NN05153610 CHIP RESISTOR 15K OHM +- 5% 1/16W
PC01 RC08 nsp NN05153610 CHIP RESISTOR 15K OHM +- 5% 1/16W
PC01 RC09 nsp NN05680610 CHIP RESISTOR 68 OHM +- 5% 1/16W
PC01 RC10 nsp NN05680610 CHIP RESISTOR 68 OHM +- 5% 1/16W
PC01 RC11 nsp NN05820610 CHIP RESISTOR 82 OHM +- 5% 1/16W
PC01 RC12 nsp NN05820610 CHIP RESISTOR 82 OHM +- 5% 1/16W
PC01 RC13 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PC01 RC14 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PC01 RC17 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PC01 RC18 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PF01 CF03 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PF01 CF04 EY47501670 EY47501670 TANTL.CAP CHIP 4.7µF/ 16V
PF01 CF05 EY47501670 EY47501670 TANTL.CAP CHIP 4.7µF/ 16V
PF01 CF06 EY10601620 EY10601620 TANTL.CAP CHIP 10µF/ 16V
PF01 CF07 EY47601620 EY47601620 TANTL.CAP CHIP 47µF/ 16V
PF01 CF08 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PF01 CF09 nsp DK98105200 CERAMIC CAP. 1µF 10V F
PF01 CF10 nsp DK96102300 CERAMIC CAP. 1000 PF +- 10% B 50V GR36
PF01 CF11 nsp DK96102300 CERAMIC CAP. 1000 PF +- 10% B 50V GR36
PF01 CF12 nsp DK96102300 CERAMIC CAP. 1000 PF +- 10% B 50V GR36
PF01 CF13 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF14 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF15 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF16 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF17 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF18 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF19 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF20 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF21 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 CF22 nsp DK96471300 CERAMIC CAP. 470PF (GR39)
PF01 DF03 HI10003980 HI10003980 L.E.D. NSCW215
PF01 DF04 HI10003980 HI10003980 L.E.D. NSCW215
PF01 DF05 HI10003980 HI10003980 L.E.D. NSCW215
PF01 DF06 HI10003980 HI10003980 L.E.D. NSCW215
PF01 LF01 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PF01 QF01 HC12243090 HC12243090 IC NJU6469LFG1
PF01 QF02 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 QF03 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 QF04 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 QF05 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 QF06 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 QF07 BA21105000 BA21105000 SEMICON.COMP DTC123JE,RN1105
PF01 RF01 NY02030160 NY02030160 TRIMM.RESISTOR EVM1S/TMC3KE/RH03AD 20K OHM
PF01 RF02 nsp NN05153610 CHIP RESISTOR 15K OHM +- 5% 1/16W
