Marantz PMD570 Service Manual

76
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P.C.B.
NAME
POS. NO.
PA01 R408 nsp NN05221610 CHIP RESISTOR 220 OHM +- 5% 1/16W
PA01 R409 nsp NN05102610 CHIP RESISTOR 1K OHM +- 5% 1/16W
PA01 R410 nsp NN05470610 CHIP RESISTOR 47 OHM +- 5% 1/16W
PA01 R411 nsp NN05750610 CHIP RESISTOR 75 OHM +-5% 1/16W
PA01 R412 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 RA01 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA02 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA03 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA04 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA15 nsp NN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16W
PA01 RA16 nsp NN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16W
PA01 RA17 nsp NN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16W
PA01 RA18 nsp NN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16W
PA01 RA19 RK02031120 RK02031120 VARIABLE RESIST RK09K111 LM1=9.5MM
PA01 RA20 RK02031120 RK02031120 VARIABLE RESIST RK09K111 LM1=9.5MM
PA01 RA21 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RA22 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RA23 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RA24 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RA25 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA26 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA27 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA28 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA29 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA30 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA31 nsp NN05392610 CHIP RESISTOR 3.9K OHM +- 5% 1/16W
PA01 RA32 nsp NN05392610 CHIP RESISTOR 3.9K OHM +- 5% 1/16W
PA01 RA33 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA34 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA35 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA36 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA37 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA38 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA39 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA40 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA41 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA42 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA43 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA44 nsp NN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16W
PA01 RA45 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA46 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RA51 nsp NN05331610 CHIP RESISTOR 330 OHM +- 5% 1/16W
PA01 RA52 nsp NN05331610 CHIP RESISTOR 330 OHM +- 5% 1/16W
PA01 RA53 nsp NN05151610 CHIP RESISTOR 150 OHM +- 5% 1/16W
PA01 RA54 nsp NN05151610 CHIP RESISTOR 150 OHM +- 5% 1/16W
PA01 RA61 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RA62 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RA63 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RA64 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RM91 nsp NN05100610 CHIP RESISTOR 10 OHM +- 5% 1/16W
PA01 RM92 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RM93 nsp NN05102610 CHIP RESISTOR 1K OHM +- 5% 1/16W
PA01 RM94 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 RM95 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 RM96 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 RM99 NI05000110 NI05000110 CHIP RESISTOR 0 OHM +- 5% 1/10W
PA01 RM99 NI05000110 NI05000110 CHIP RESISTOR 0 OHM +- 5% 1/10W
PA01 RR01 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RR02 nsp NN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16W
PA01 RR03 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 RR11 nsp NN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16W
PA01 RX81 nsp NN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16W
PA01 RX82 nsp NN05154610 CHIP RESISTOR 150K OHM +- 5% 1/16W
PA01 SR01 SP02022320 SP02022320 PUSH SWITCH PUSH SW (SPUJ191000) W/KNOB
PC01 CC01 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PC01 CC02 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PC01 CC03 nsp DD95220300 CERAMIC CAP. 22 PF +- 5% CG 50V GR39
PC01 CC04 nsp DD95220300 CERAMIC CAP. 22 PF +- 5% CG 50V GR39
PC01 CC07 nsp DK96222300 CERAMIC CAP. 2200PF (GR39)
PC01 CC08 nsp DK96222300 CERAMIC CAP. 2200PF (GR39)
