Marantz PMD570 Service Manual

75
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P.C.B.
NAME
POS. NO.
PA01 CA19 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA20 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA21 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA22 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA23 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 CA24 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 CA25 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA26 nsp DK96104300 CERAMIC CAP. C1608X7R1H104K
PA01 CA27 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PA01 CA28 nsp OA47602520 ELECT. CAP. 47 µF M 25V RA-2
PA01 CA31 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 CA32 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 CA33 nsp OA10701620 ELECT. CAP. 100 µF M 16V RA-2
PA01 CA34 nsp OA10701620 ELECT. CAP. 100 µF M 16V RA-2
PA01 CM91 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CM92 nsp DD95221300 CERAMIC CAP. 220 PF +- 5% CG 50V GR39
PA01 CR01 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR03 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR05 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR07 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR09 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR11 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR13 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PA01 CR14 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PA01 CR15 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PA01 CR16 nsp DD95101300 CERAMIC CAP. 100 PF +- 5% CG 50V GR39
PA01 CR17 nsp DK96103300 CERAMIC CAP. 0.01µF +-10% 50V C1608JB1H103K
PA01 CR21 nsp DD95220300 CERAMIC CAP. 22 PF +- 5% CG 50V GR39
PA01 CX81 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 CX82 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 CX83 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 CX84 nsp DD95470300 CERAMIC CAP. 47 PF +- 5% CG 50V GR39
PA01 J201 YT02041040 YT02041040 TERMINAL 14X14 RA 2L4P W/R NI FRNT-GND
PA01 J401 YT02021230 YT02021230 TERMINAL 14X14 RA 2L2P BLK NI FLM-GND
PA01 JA01 YJ01004340 YJ01004340 JACK NC3FAH2 4P CANON TYPE HOLZ
PA01 JA02 YJ01004340 YJ01004340 JACK NC3FAH2 4P CANON TYPE HOLZ
PA01 JM91 YJ01003050 YJ01003050 JACK O3.5 HEAD PHONE JACK HLJ0521
PA01 JM92 YJ01004520 YJ01004520 JACK 4P MINI JACK HSJ 1637-010512
PA01 JR01 YT02090160 YT02090160 TERMINAL D-SUB 9PIN F
PA01 JX81 YJ90014590 YJ90014590 JACK USB CONNECTOR CMS1410
PA01 L251 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 L252 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 L253 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 L254 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 L401 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 L403 TP41042010 TP41042010 TRANSF. PULS TRANS FOR CD
PA01 L404 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 LA01 FC90020110 FC90020110 FERRITE CORE 47 PF +- 5% CG 50V GR39
PA01 LA02 FC90020110 FC90020110 FERRITE CORE 47 PF +- 5% CG 50V GR39
PA01 LA03 FC90020110 FC90020110 FERRITE CORE 47 PF +- 5% CG 50V GR39
PA01 LA04 FC90020110 FC90020110 FERRITE CORE 47 PF +- 5% CG 50V GR39
PA01 LM91 FN31010030 FN31010030 EMI FILTER BLM11B102S 1608 EMIFILTER
PA01 LX81 FC90020110 FC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PA01 LX82 FC90020110 FC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PA01 Q251 HC10102090 HC10102090 IC NJM2068M TAPING
PA01 QA01 HC10102090 HC10102090 IC NJM2068M TAPING
PA01 QA02 HC10102090 HC10102090 IC NJM2068M TAPING
PA01 QA03 HC10102090 HC10102090 IC NJM2068M TAPING
PA01 QR01 HC10292060 HC10292060 IC UPD4721GS-GJG IC RS232C
PA01 R251 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R252 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R253 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R254 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R257 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 R258 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 R259 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R260 nsp NN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16W
PA01 R401 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
PA01 R402 nsp NN05750610 CHIP RESISTOR 75 OHM +-5% 1/16W
PA01 R405 nsp NN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16W
