Marantz SR-19EX - Page 46

72
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
P104-7CH ELE. VOL. TUNER
CIRCUIT BOARD
P104-CAPACITORS
CA01 4822 125 50384 TRIM VCT51E 20pF CT12000200
CA02 CER. CHIP 0.047
F B 50V DK56473300
CA03 4822 122 33204 CER. CHIP 15pF
5% DD55150300
CA04 4822 121 42466 FILM 390pF 100V ECQ-P DF15391550
CA05 5322 122 32452 CER. CHIP 47pF
5% CH DD55470300
CA06 5322 122 34098 CER. CHIP 0.01UF
10% DK56103300
CA18 4822 124 22274 ELECT 4.7
F M 50V RA-2 OA47505020
CC05 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CC06 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CC07 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC08 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CC25 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CC26 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CC27 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CC29
4822 124 90353 ELECT 100 F M 10V RA-2 OA10701020
CC32
CC33
4822 126 12061 CER. CHIP 0.1 F B 25V DK56104200
CC37
CC40 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CM01
CER. CHIP 470pF 5% DD55471300
CM08
CM09 5322 122 32531 CER. CHIP 470pF
5% DD55101300
CM10 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CM11 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CM12 4822 124 22277 ELECT 470
F 16V M RA-2 OA47701620
CM21
4822 122 33575 CER. CHIP 220pF 5% DD55221300
CM28
CM29
CER. CHIP 470pF 5% DD55471300
CM35
CG51 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CG52 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CG53 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CG54 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CG55 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CG56 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CG57 ELECT 22
F 25V EA22602520
CG58 ELECT 22
F 25V EA22602520
CG59 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CG60 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CG61 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CG62 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CG63 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CG64 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CG65 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CG66 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CG67 4822 124 22782 ELECT 47
F 16V EA47601620
CG68 4822 124 22782 ELECT 47
F 16V EA47601620
CG69 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CG70 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CG71 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CG72 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CG73 5322 122 32531 CER. CHIP 100pF
±
5% DD55101300
CG75 ELECT 22
F 25V EA22602520
CG76 ELECT 22
F 25V EA22602520
CV01 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV02 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV03 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV04 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV05 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV06 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV07 ELECT 22
F 25V EA22602520
CV08 ELECT 22
F 25V EA22602520
CV09 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV10 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV11 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV12 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV13 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV14 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV15 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV16 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV17 4822 124 22782 ELECT 47
F 16V EA47601620
CV18 4822 124 22782 ELECT 47
F 16V EA47601620
CV19 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CV20 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CV21 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CV22 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CV23 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV25 ELECT 22
F 25V EA22602520
CV26 ELECT 22
F 25V EA22602520
CV27 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV28 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV29 ELECT 22
F 25V EA22602520
CV30 ELECT 22
F 25V EA22602520
CV31 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CV32 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CV41 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV42 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV43 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV44 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV45 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV46 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV47 ELECT 22
F 25V EA22602520
CV48 ELECT 22
F 25V EA22602520
CV49 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV50 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV51 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV52 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV53 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV54 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV55 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV56 5322 122 32531 CER. CHIP 100pF
±
5% DD55101300
CV57 4822 124 22782 ELECT 47
F 16V EA47601620
CV58 4822 124 22782 ELECT 47
F 16V EA47601620
CV59 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CV60 4822 126 12061 CER. CHIP 0.1
F B 25V DK56104200
CV61 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CV62 4822 124 22698 ELECT 47
F M 25V RA-2 OA47602520
CV63 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV65 4822 124 41534 ELECT 10
F M 25V RA-2 OA10602520
CV66 4822 124 41534 ELECT 10
F M 25V RA-2 OA10602520
CV71 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV73 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV74 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV75 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV76 5322 122 32531 CER. CHIP 100pF
5% DD55101300
CV77 ELECT 22
F 25V EA22602520
CV78 ELECT 22
F 25V EA22602520
CV79 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV80 4822 124 90358 ELECT 22
F M 16V RA-2 OA22601620
CV81 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CV82 4822 124 22276 ELECT 47
F M 50V RA-2 OA47605020
CV83 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV84 5322 122 34098 CER. CHIP 0.01
F 10% DK56103300
CV85 5322 122 32531 CER. CHIP 100pF
5% DD55101300
