Marantz SR-19EX - Page 49

75
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
R508 4822 111 90919 CHIP 47k 5% 1/10W NI05473110
R509 4822 111 90907 CHIP 22k
5% 1/10W NI05223110
R510 4822 111 90918 CHIP 4.7k
5% 1/10W NI05472110
R511 4822 111 90926 CHIP 8.2k
5% 1/10W NI05822110
R513 4822 111 90895 CHIP 10k
5% 1/10W NI05103110
R515 4822 111 90895 CHIP 10k
5% 1/10W NI05103110
P104-SEMICONDUCTORS
DA01 4822 125 50416 VARICAP SVC342-L HD40009030
DA05 9965 000 03400 CHIP DIODE MA716 HZ20030020
DC01 9965 000 03401 CHIP DIODE RB425D HZ20030210
DM01
4822 130 33944 CHIP DIODE DAN202K HZ20002210
DM04
DM05
DIODE 1SS200 HE10202050
DM09
DM10 9965 000 03401 CHIP DIODE RB425D HZ20030210
DM11 9965 000 03401 CHIP DIODE RB425D HZ20030210
DM12 9965 000 03401 CHIP DIODE RB425D HZ20030210
D202 9965 000 03403 CHIP DIODE ZENER 02CZ9.1-X HZ30031050
D504 9965 000 03401 CHIP DIODE RB425D HZ20030210
QC01 4822 209 32554 IC LC78213 HC10310030
QC03 IC NJM4580DD HC10112090
QC07 TRS. 2SC2120 O HT321201A0
QC08 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QM01
4822 130 11511 CHIP TRS. 2SC3326 A OR B HX333262A0
QM08
QM09
QM13
4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QM15 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
QM16 DIG. TRS. RN2402 BA1000605R
QM17 4822 209 90532 IC NJU3713D HC10161090
QG51 9965 000 01359 IC TC9459N ELE.VOLUME HC10443050
QG52 4822 209 73064 IC NJM-2068-DD HC10053090
QG53 4822 209 73064 IC NJM-2068-DD HC10053090
QV01 9965 000 01359 IC TC9459N ELE.VOLUME HC10443050
QV02 9965 000 01359 IC TC9459N ELE.VOLUME HC10443050
QV03 9965 000 01359 IC TC9459N ELE.VOLUME HC10443050
QV05 4822 209 73064 IC NJM-2068-DD HC10053090
QV06 4822 209 73064 IC NJM-2068-DD HC10053090
QV07 4822 209 73064 IC NJM-2068-DD HC10053090
QV09 4822 209 73064 IC NJM-2068-DD HC10053090
QV10 4822 209 73064 IC NJM-2068-DD HC10053090
QV11 4822 209 73064 IC NJM-2068-DD HC10053090
QV13 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QV14 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QV15
4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
QV18
QV19 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QV20 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q201 9965 000 01369 IC LA1837 FM AM IF MPX IC HC10384030
Q202 4822 130 62294 TRS. 2SC1809S P
150MW 500MHz
HT318091P0
Q203 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q204 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q205 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q301 /C,/K,/S 4822 209 73064 IC NJM-2068-DD HC10053090
Q351 /S IC RDS DECODER LC72722 HC10404030
Q352 /S 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q353 /S 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
Q354 /S 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
Q501 9965 000 01370 IC LC72130 HC10394030
P104-MISCELLANEOUS
A101 9965 000 01368 VHF TUNER TFFJ4E AV00903010
FA01 CERAMIC FILTER SFZ450JL3
CERAFIL 451K
FF10045410
F201 /C,/K,/S 4822 242 70665 CERAMIC FILTER
SFE10.7MS3-A
FF11070620
F201 /U 4822 242 70911 CERAMIC FILTER
SFF10.7MA8-A
FF11070610
F202 4822 242 70665 CERAMIC FILTER
SFE10.7MS3-A
FF11070620
JM01 TERMINAL RCA 4P BLACK YT02041160
JM02 4822 265 10681 TERMINAL RCA 6P BLACK YT02060540
JM03 TERMINAL RCA 4P BLACK YT02041160
JM05 4822 265 10684 TERMINAL RCA 1P BLACK YT02011020
J101 4822 290 81632 TERMINAL YKD31-0215A
FM AM ANT PAL
YT03030020
LA01 4822 157 63084 ANT COIL MW ANT 280
H LA10295170
LA02 4822 157 70779 OSC. COIL MW OSC C01L LO70013010
LA05 4822 157 53589 CHOKE COIL TL-8 393J LC23960710
LA06 4822 148 81095 I.F.T. COIL AM IFT K7-H5
FOR SFP450D
LI70033510
LC01 9965 000 01570 RELAY ED2-24 LY20240470
LM01
9965 000 01576 RELAY MR82-24USR LY20240480
LM04
L201 4822 157 63904 I.F.T. COIL FM DET
M292BEAS-5968Z
LI70376010
L301 4822 157 71731 M.P.X. COIL
LPF-V10-A1 19 38KHz
LS10293020
L302 4822 157 71731 M.P.X. COIL
LPF-V10-A1 19 38KHz
LS10293020
L350 /S 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L351 /S 4822 242 73843 EMI FILTER DSS306-91-F-233Z FM12223010
L352 /S
4822 111 90892 CHIP 0
Ω±
5% 1/10W NI05000110
L356 /S
L359 /S 4822 111 90892 CHIP RES. 0
5% 1/10W NI05000110
L501 4822 111 90892 CHIP RES. 0
5% 1/10W NI05000110
L502 4822 111 90892 CHIP RES. 0
5% 1/10W NI05000110
L503 4822 111 90892 CHIP RES. 0
5% 1/10W NI05000110
L504 4822 111 90892 CHIP RES. 0
5% 1/10W NI05000110
X351 /S 4822 242 10857 CRYSTAL 4.332MHz AT-49 JX04003260
X501 4822 242 72333 CRYSTAL AD0618CTB 7.2MHz JX07001260
U093 4822 122 30043 CER. CAP. 0.01
F Z 50V DK18103310
P604-AC-2 DTS&THX EX
DECODE CIRCUIT BOARD
P604-CAPACITORS
CD01 5322 126 11578 CER. CHIP 1000pF B 50V DK96102300
CD02 4822 126 11687 CER. CHIP 0.1
F +80% -20% DK98104200
CD03 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CD04 4822 124 90353 ELECT 100
F M 10V RA-2 OA10701020
CD05 4822 126 11687 CER. CHIP 0.1
F +80% -20% DK98104200
CD51 4822 126 11687 CER. CHIP 0.1
F +80% -20% DK98104200
CD52 4822 124 90352 ELECT 10
F M 16V RA-2 OA10601620
CD53 4822 126 11687 CER. CHIP 0.1
F +80% -20% DK98104200
CD54 4822 126 11687 CER. CHIP 0.1
F +80% -20% DK98104200
CD55 4822 124 90352 ELECT 10 F M 16V RA-2 OA10601620
