Marantz SR-19EX - Page 59

85
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
C825 4822 124 22571 ELECT 10 F M 50V RA-2 OA10605020
C826 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C827 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C828 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C830 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
C832 9965 000 01352 ELECT 470
F 63V EA47706310
C833 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
C834 ELECT 47
F M 35V RA-2 OA47603520
C835 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C836 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C840 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
C841 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C843 4822 124 90355 ELECT 100
F M 50V RA-2 OA10705020
C844 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C845 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C847 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C848 4822 122 30043 CER. 0.01
F Z 50V DK18103310
C851 4822 124 41538 ELECT 220
F 35V M RA-2 OA22703520
C852 4822 124 90357 ELECT 2.2
F M 50V RA-2 OA22505020
PS04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR
10% 50V :
( CG07 CG08 [/S] ) CQ06 CQ07
( CS37-CS54 CS71 CS72 CS91
CS92 CS95 CS96 [/S] )
ELECTROLYTIC CAPACITOR
20% : C823 C842 C849
PS04-RESISTORS
RG15 4822 115 90166 FUSE 10 G 1/4W NF02100140
R804 4822 117 10158 1 5% 1/4W GG05010140
R807 4822 053 10222 2.2k
5% 1W GA05222010
R811 4822 111 90731 FUSE 47 G 1/4W NF02470140
R817 4822 115 90167 FUSE 100 G 1/4W NF02101140
PS04-RESISTORS(COMMON)
CARBON FILM FIXED RES.
5% 1/6W : R806 R808-R810
R812 R814-R816 R819
RG01-RG06 RG09-RG14
RG16-RG20 RQ25-RQ30
RS01-RS10 RS13-RS42
RS47-RS95 RS98 RS99
PS04-SEMICONDUCTORS
DG01 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DG02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DG03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DS01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DS02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D803
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D806
!D808 4822 130 83438 DIODE D5SB-20 5A 200V HE20016290
D810 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D811 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D812 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D813 ZENER DIODE MTZJ36D HD33601000
D814 4822 130 80318 ZENER DIODE ZENER 6.8V HD30681000
D815
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D825
D826 DIODE 1GWJ43 HD20031050
D828 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D829 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D830 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QG01 9965 000 01359 IC ELE.VOL.TC9459N HC10443050
QG02 4822 209 83631 IC NJM4558D-D HC10008090
QG03 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
QG04 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QG05 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QG06 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QG07 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QS01
4822 209 83631 IC NJM4558D-D HC10008090
QS11
QS12 4822 209 32552 IC LC78211 HC10308030
QS13 4822 209 32553 IC LC78212 HC10309030
QS14 4822 209 32553 IC LC78212 HC10309030
QS15 4822 209 32552 IC LC78211 HC10308030
QS16 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QS17
4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS20
QS21 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QS22 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QS23 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS24 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS25 4822 209 83631 IC NJM4558D-D HC10008090
QS26 4822 130 90347 PHOTO UNIT PC-817
CUPLER 1PAIR
HW10006320
QS27 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q802 9965 000 01354 IC L780S15 +15V 1A HC38915030
Q803 4822 209 31864 IC NJM7915FA -15V 1A HC39915090
Q804 TRS. 2SD1415 HT41415100
Q805 4822 209 31864 IC NJM7915FA -15V 1A HC39915090
Q807 4822 209 63179 IC NJM7905FA -5V 1A HC39905090
Q808 4822 209 61533 IC NJM7806FA +6V HC38906090
Q809 4822 130 61666 TRS. 2SA3419 Y HT334192A0
Q810 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
Q811 4822 209 14883 IC V-SENSOR IC S-806C 4.55V HC10075530
Q812 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q813 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
PS04-MISCELLANEOUS
JS01 4822 267 31451 TERMINAL RCA JACK 8P
WHITE RED
YT02080110
JS03 4822 265 10748 TERMINAL RCA JACK 6P
WHITE RED
YT02060460
JS04 4822 265 10748 TERMINAL RCA JACK 6P
WHITE RED
YT02060460
JS06 4822 265 10748 TERMINAL RCA JACK 6P
WHITE RED
YT02060460
JS07 9965 000 01355 TERMINAL RCA 4P
ORANGE GREEN
YT02041260
LG01 9965 000 01576 RELAY MR82-24USR LY20240480
L801 9965 000 01353 RELAY FTR-F1AA024T LY20240460
