Marantz SR-19EX - Page 61

87
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
PW04-HEADPHONE
CIRCUIT BOARD
PW04-CAPACITORS
CW01 4822 122 40586 CER. 10000pF
20% DA17103110
CW02 4822 122 40586 CER. 10000pF
20% DA17103110
CW03 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
CW04 4822 122 40617 CER. 0.1
F +80% -20% 50V DD38104010
PW04-MISCELLANEOUS
JW01 /C,/K,/S JACK HLJ2307-01-3163 YJ01004330
JW01 BLACK 4822 265 10685 JACK HLJ2307-01-3160 YJ01004240
JW01 GOLD JACK HLJ2307-01-3163 YJ01004330
PY04-U-COM CIRCUIT BOARD
PY04-CAPACITORS
CY01 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY02 4822 124 23056 ELECT 47
µ
F 10V EJ47601010
CY04 DK96103200
CY07 4822 126 13303 CER. 1
F 10V F DK98105200
CY08 5322 126 11583 CER. 0.01
F 10% B 25V DK96103200
CY09 5322 126 11583 CER. 0.01
F 10% B 25V DK96103200
CY10 5322 126 11583 CER. 0.01
F 10% B 25V DK96103200
CY11 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY12 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY13 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY19 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY25 5322 126 11578 CER. 1000pF
10% B 50V DK96102300
CY26 4822 126 11687 CER. 0.1
F +80% -20% DK98104200
CY30 BIG ELECT 1F 5.5V
DB-5R5D105
EX10500530
PY04-RESISTORS CHIP
RY01 4822 051 30479 47
5% 1/16W NN05470610
RY02 4822 116 83819 18k
5% 1/16W NN05183610
RY03 4822 051 30473 47k
5% 1/16W NN05473610
RY04 4822 051 30473 47k
5% 1/16W NN05473610
RY05 4822 051 30473 47k
5% 1/16W NN05473610
RY06
4822 051 30103 10k 5% 1/16W NN05103610
RY11
RY12 4822 051 30105 1M
5% 1/16W NN05105610
RY13 4822 051 30103 10k
5% 1/16W NN05103610
RY14 /C,/K,/S 4822 051 30473 47k
5% 1/16W NN05473610
RY15 /U 4822 116 82487 0
5% 1/16W NN05000610
RY16 /C,/K,/S 4822 051 30473 47k
5% 1/16W NN05473610
RY17 /U 4822 116 82487 0
5% 1/16W NN05000610
RY19 4822 116 82487 0
5% 1/16W NN05000610
RY20 4822 051 30473 47k
5% 1/16W NN05473610
RY22 /S 4822 051 30473 47k
5% 1/16W NN05473610
RY23 /C,/K,/U 4822 116 82487 0
5% 1/16W NN05000610
RY24 4822 051 30472 4.7k
5% 1/16W NN05472610
RY25 4822 051 30472 4.7k
5% 1/16W NN05472610
RY27
4822 051 30472 4.7k 5% 1/16W NN05472610
RY31
RY32 4822 116 82487 0
5% 1/16W NN05000610
RY33 4822 116 82487 0
5% 1/16W NN05000610
RY34 4822 116 82487 0
5% 1/16W NN05000610
RY35 4822 051 30221 220
5% 1/16W NN05221610
RY36 4822 116 82487 0
5% 1/16W NN05000610
RY37 4822 116 82487 0
5% 1/16W NN05000610
RY38
4822 051 30221 220 5% 1/16W NN05221610
RY45
RY46
4822 116 82487 0 5% 1/16W NN05000610
RY56
RY57 4822 051 30473 47k
5% 1/16W NN05473610
RY58 4822 051 30103 10k
5% 1/16W NN05103610
RY59 4822 051 30683 68k
5% 1/16W NN05683610
RY60 4822 051 30103 10k
5% 1/16W NN05103610
RY64 4822 051 30273 27k
5% 1/16W NN05273610
RY65 4822 051 30221 220
5% 1/16W NN05221610
RY66 4822 051 30221 220
5% 1/16W NN05221610
RY67 4822 051 30103 10k
5% 1/16W NN05103610
RY68 4822 051 30273 27k
5% 1/16W NN05273610
RY69 4822 122 40617 CER. 0.1 F +80% -20% 50V DD38104010
PY04-SEMICONDUCTORS
DY01 4822 130 80522 CHIP DIODE 1SS301 DAN202U HZ21006000
DY02 4822 130 80522 CHIP DIODE 1SS301 DAN202U HZ21006000
DY03 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DY04 4822 130 80522 CHIP DIODE 1SS301 DAN202U HZ21006000
QY01 MICROPROCESSOR
TMP93PW40DF
HU326JT00F
QY02 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
QY03 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY04 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
QY05 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY06 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY07 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QY08 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY09 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QY10 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY11 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
QY12 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
QY13 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QY14 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY15 4822 209 12845 IC S-80730SN-DT-X RESET IC HC10054530
PY04-MISCELLANEOUS
JY01 JACK 33PIN ANGLE
FFC33FE-ST-VK-N
YJ07020290
XY01 9965 000 01346 SERAMIC VIB.
CST20.00MXW0H1 20MHz+C
FQ02005030
PY54-CONNECT
CIRCUIT BOARD
JY51 JACK 33FE-BT-VK-N 33PIN YJ07020660
JY53 JACK 33FE-BT-VK-N 33PIN YJ07020660
PY64-CONNECT-0
CIRCUIT BOARD
PY64-CAPACITORS
CY61 4822 122 30043 CER. 0.01 F Z 50V DK18103310
CY62 4822 124 22571 ELECT 10 F M 50V RA-2 OA10605020
PY64-RESISTOR
RY61 4822 115 90167 FUSE 100
G 1/4W NF02101140
PY64-RESISTORS(COMMON)
CARBON FILM FIXED RES.
5% 1/6W : RY62 RY63
R
