Marantz SR-19EX - Page 63

89
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
PZ04-SEMICONDUCTORS
DX01 4822 130 80321 ZENER DIODE ZENER 10V HD31001000
DZ01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ05 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ19 9965 000 01374 ZENER DIODE MTZJ2.7B HD30271000
DZ21 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ22 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QX01
QX04
4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
QX05 /C,/K,/S 4822 130 63211 DIG. TRS.
DTA114TS UN4115 10K
BA10004000
QX07 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QZ01 9965 000 01371 IC MM1140XF HC10083550
QZ02 IC BA7612N HC10201210
QZ03 9965 000 01371 IC MM1140XF HC10083550
QZ04 IC BA7612N HC10201210
QZ05 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QZ06 IC BA7613N HC10202210
QZ07 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QZ08 IC BA7612N HC10201210
QZ09 4822 209 32246 IC NJM2244
3IN SW 75 W DRIVER
HC10119090
QZ10 9965 000 01379 IC NJM2263D HC10198090
QZ11 IC OSD IC LC74781 HC10377030
QZ12 /C,/K,/S 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QZ13 /C,/K,/S 4822 130 61189 DIG. TRS.
DTC114TS UN4215 10k
BA20004000
QZ14 /C,/K,/S 4822 130 61189 DIG. TRS.
DTC114TS UN4215 10k
BA20004000
QZ16 IC BA7613N HC10202210
QZ17 IC BA7613N HC10202210
QZ18 IC BA7613N HC10202210
QZ19 4822 209 32246 IC NJM2244
3IN SW 75 W DRIVER
HC10119090
QZ20 9965 000 01379 IC NJM2263D HC10198090
QZ21 DIG. TRS. DTC144VSA 47k 10k BA20068210
QZ22 9965 000 01380 IC 74HC4051 HC705100B0
QZ23 4822 209 83088 IC NJM2903D HC10022090
QZ24 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QZ25 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QZ26 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
QZ27 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QZ28 9965 000 01381 IC 74HC32 HC703200B0
QZ29 IC TC74HC132AP HC713205D0
PZ04-MISCELLANEOUS
JZ01 4822 265 31302 TERMINAL S-VIDEO JACK 3P YT02030350
JZ02 4822 265 20725 TERMINAL S-VIDEO JACK 2P YT02021320
JZ03 4822 265 31302 TERMINAL S-VIDEO JACK 3P YT02030350
JZ04 TERMINAL 6P
GREEN BLUE RED
YT02060710
JZ05 TERMINAL RCA J6P
GREEN BLUE RED
YT02060710
LX01 4822 157 62909 CHOKE COIL 22
H LC12233800
LZ01 4822 157 62922 CHOKE COIL L 33
H LC13333800
LZ02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LZ03 4822 242 73843 EMI FILTER DSS306-91-F-233Z FM12223010
XZ01 /C,/K,/S 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
XZ02 4822 242 80288 CRYSTAL AT49 14.31818MHz JX14001260
