Marantz SR4320/A1B User Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
31
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
FRONT CIRCUIT BOARD
BN91 nsp nsp
WIRE ASS'Y
CWB2B908350EN
BN92 nsp nsp
WIRE ASS'Y
CWB2B904150EN
BN93 nsp nsp
WIRE ASS'Y
CWB2B903050EN
BN94 nsp nsp
WIRE ASS'Y
CWB2B902080EN
C901
nsp nsp
CAP. CERAMIC
0.01µF 50V Z HCBS1H103ZFT
C904
C905 nsp OA47605020
CAP. ELECT
47µF 50V HCEA1HH470T
C906 nsp nsp
CAP. CERAMIC
0.01µF 50V ZF CCKT1H103ZF
C907 nsp OA47605020
CAP. ELECT
47µF 50V HCEA1HH470T
C909 *EX000050R *EX000050R
CAP. GOLD
JP EECS0HD104V BCES0HD104
C910 nsp nsp
CAP. CERAMIC
0.01µF 50V ZF CCKT1H103ZF
C911 nsp nsp
CAP. CERAMIC
18pF 50V JC HCBS1H180JCT
C912 nsp nsp
CAP. CERAMIC
18pF 50V JC HCBS1H180JCT
C913 nsp OA10505020
CAP. ELECT
1µF 50V HCEA1HH1R0T
C914 nsp nsp
CAP. CERAMIC
0.01µF 50V Z HCBS1H103ZFT
C915 nsp OA47605020
CAP. ELECT
47µF 50V HCEA1HH470T
C916 nsp nsp
CAP. CERAMIC
0.01µF 50V ZF CCKT1H103ZF
C917 nsp nsp
CAP. CERAMIC
0.01µF 50V Z HCBS1H103ZFT
C918 nsp nsp
CAP. CERAMIC
0.01µF 50V Z HCBS1H103ZFT
C919 nsp nsp
CAP. CERAMIC
0.01µF 50V Z HCBS1H103ZFT
C920 /A/N nsp nsp
CAP. CERAMIC
1000pF 50V KB CCKT1H102KB
C921 /A/N nsp nsp
CAP. CERAMIC
27pF 50V JC CCCT1H270JC
C922 /A/N nsp nsp
CAP. CERAMIC
27pF 50V JC CCCT1H270JC
C923 /A/N nsp OA10701620
CAP. ELECT
100µF 16V HCEA1CH101T
C924 /A/N nsp nsp
CAP. CERAMIC
0.022µF 50V ZF CCKT1H223ZF
C925 /A/N nsp nsp
CAP. CERAMIC
1000pF 50V KB CCKT1H102KB
C926 /A/N nsp OA22505020
CAP. ELECT
2.2µF 50V HCEA1HH2R2T
C927 /A/N nsp nsp
CAP. CERAMIC
1000pF 50V KB CCKT1H102KB
C928 /A/N nsp nsp
CAP. CERAMIC
560pF 50V KB CCKT1H561KB
C934 nsp nsp
CAP. CERAMIC
0.1µF 50V Z CCKT1H104ZF
C935 nsp OA22505020
CAP. ELECT
2.2µF 50V HCEA1HH2R2T
CN95 nsp nsp
WAFER, CARD
GF-102-18S-TS KJP18GA117ZG
D901 nsp *HD201740R
DIODE
1SS133T-77 HVD1SS133MT
D902 *HI101040R *HI101040R
L.E.D. RED
SLR342VCTB7T089 HVD342VCTB7T089
D903 /A/N HD30511000 HD30511000
DIODE, ZENER
MTZJ5.1BT(5.1V 1/2W) HVDMTZJ5.1BT
D904 nsp *HD201740R
DIODE
1SS133T-77 HVD1SS133MT
D905 *HI101040R *HI101040R
L.E.D. RED
SLR342VCTB7T089 HVD342VCTB7T089
D906 *HI101040R *HI101040R
L.E.D. RED
SLR342VCTB7T089 HVD342VCTB7T089
D907 *HI101040R *HI101040R
L.E.D. RED
SLR342VCTB7T089 HVD342VCTB7T089
D908 nsp *HD201740R
DIODE
1SS133T-77 HVD1SS133MT
D910 nsp *HD201740R
DIODE
1SS133T-77 HVD1SS133MT
D911 *HD302140R *HD302140R
DIODE, ZENER
MTZJ4.3CT(4.3V 1/2W) HVDMTZJ4.3CT
FIP1 *HQ300350R *HQ300350R
F.I.P.
SVA09MS10 KFLSVA09MS10
IC91 *HS19AWT0R *HS19AWT0R
I.C. O.T.P.
TMP87PM78F HVITMP87PM78F
IC92 *HW100650R *HW100650R
SENSOR, REMOTE
RPM6936-H4 HRVRPM6936H4
IC93 /A/N *HC108200R *HC108200R
I.C. RDS FILTER
TW SAA6579T/V1 BVISAA6579TV1
Q901 *BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q902 *BA001450R *BA001450R
TRS.
KRA107M HVTKRA107MT
Q903 *BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q904 *HT700060R *HT700060R
TRS.
KSB811Y HVTKSB811YT
Q905
*BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q908
Q909 *HT100390R *HT100390R
TRS.
KSA1175Y HVTKSA1175YT
Q910 *BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q911 *BA001450R *BA001450R
TRS.
KRA107M HVTKRA107MT
Q912 *BA001450R *BA001450R
TRS.
KRA107M HVTKRA107MT
Q913 *BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q914 *BA001460R *BA001460R
TRS.
KRC107M HVTKRC107MT
Q916 *BA001450R *BA001450R
TRS.
KRA107M HVTKRA107MT
R901 nsp nsp
RES. CARBON
10kΩ 1/5W J
CRD20TJ103T
R902 /A/N nsp nsp
RES. CARBON
10kΩ 1/5W J
CRD20TJ103T
