Marantz SR5002 Service Manual

2
Surround
Mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW
Signal format indicators Channel status
AUTO
Dolby Surr. EX Dolby Digital EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D(2ch) Dolby Digital 2.0 O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Pro Logic IIx movie OOOOO
2 DIGITAL , 2 SURROUND
L, R, S
DTS-ES DTS-ES OOOOOdts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS 96/24 OOO - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM OOO - O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz OOO - O PCM L, C, R, SL, SR, LFE
PCM(Audio) PCM (Stereo) O ---O PCM L, R
PCM 96kHz PCM (96kHz Stereo) O ---O PCM L, R
HDCD PCM (Stereo) O ---O PCM HDCD L, R
Analog Stereo O ---O ANALOG -
SOURCE DIRECT
PURE DIRECT
Dolby Surr. EX Dolby Digital EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Digital 2.0 O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Pro Logic IIxmovie OOO --
2 DIGITAL , 2 SURROUND
L, R, S
DTS-ES DTS-ES OOOOOdts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS 96/24 OOO - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM OOO - O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz OOO - O PCM L, C, R, SL, SR, LFE
PCM (Audio) PCM (Stereo) O - - - - PCM L, R
PCM 96kHz PCM (96kHz Stereo) O - - - - PCM L, R
HDCD PCM (Stereo) O - - - - PCM HDCD L, R
Analog Stereo O - - - - ANALOG -
EX/ES
Dolby Surr. EX Dolby Digital EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital EX OOOOO
2 DIGITAL
L, C, R, SL, SR, LFE
DTS-ES DTS-ES OOOOOdts , ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-ES OOOOOdts 96/24 L, C, R, SL, SR, LFE
DTS(5.1ch) DTS-ES OOOOOdts L, C, R, SL, SR, LFE
Multi CH-PCM
Multi Ch-PCM + Dolby EX OOOOOPCM L, C, R, SL, SR, LFE
AAC (5.1ch) AAC EX OOO - O AAC L, C, R, SL, SR, LFE
DOLBY
(PL IIxmovie)
(PL IIx music)
(PL IIx game)
(Pro Logic)
Dolby Surr. EX Dolby Digital 5.1 OOO * O
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO * O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic II x OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Pro Logic IIx OOOOO
2 DIGITAL , 2 SURROUND
L, R, S
Multi Ch-PCM Multi Ch-PCM + PLII x OOOOOPCM L, C, R, SL, SR, LFE
PCM (Audio) Pro Logic II x OOOOOPCM L, R
Analog Pro Logic II x OOOOOANALOG -
DTS
(Neo:6 Cinema)
(Neo:6 Music)
DTS-ES DTS 5.1 OOO - O dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS 96/24 OOO - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
PCM (Audio) Neo:6 OOOOOPCM L, R
Analog Neo:6 OOOOOANALOG -
Dolby D (2ch) Neo:6 OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Neo:6 OOOOO
2 DIGITAL , 2 SURROUND
L, R, S
CS II Cinema
CS II Music
CS II
Mono
PCM (Audio) CS II OOOOOPCM L, R
Analog CS II OOOOOANALOG -
Dolby D (2ch) CS II OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) CS II OOOOO
2 DIGITAL , 2 SURROUND
L, R, S
SR4002-5002NDFU01E22.indd35 07.7.1811:45:44AM
Notes:
• Dolby Digital (2 ch: Lt/Rt): signal with Dolby
Surround fl ag Speakers are full set.
• No sound outputs from the surround speaker, center
speaker and subwoofer if the DVD disc has no
surround data.
Abbreviations
L/R : Front speakers
C : Center speaker
SL/SR : Surround speakers
SBL/SBR : Surround Back speakers
SubW : Sub woofer speaker
Surround
Mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW
Signal format indicators Channel status
STEREO
Dolby Surr. EX Stereo O ---O
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Stereo O ---O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Stereo O ---O*
2 DIGITAL
L, R
Dolby D (2ch Surr) Stereo O ---O*
2DIGITAL , 2 SURROUND
L, R, S
DTS-ES Stereo O ---O dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Stereo O ---O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Stereo O ---O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Stereo O ---O PCM L, C, R, SL, SR, LFE
PCM (Audio) Stereo O ---O PCM L, R
PCM 96kHz Stereo O ---O PCM L, R
HDCD PCM (Stereo) O ---O PCM HDCD L, R
Analog Stereo O ---O ANALOG -
Virtual
Dolby Surr. EX Virtual O ----
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Virtual O ----
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Virtual O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Virtual O ----
2 DIGITAL , 2 SURROUND
L, R, S
DTS-ES Virtual O ----dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch)
Virtual O ----dts L, C, R, SL, SR, LFE
Multi Ch-PCM Virtual O ----PCM L, C, R, SL, SR, LFE
PCM (Audio) Virtual O ----PCM L, R
Analog Virtual O ----ANALOG -
Multi Ch.
Stereo
Dolby Surr. EX Dolby Digital EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Multi Channel Stereo OOOOO*
2 DIGITAL
L, R
Dolby D (2ch Surr) Multi Channel Stereo OOOOO*
2 DIGITAL , 2 SURROUND
DTS-ES DTS-ES OOOOOdts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS 96/24 OOOOOdts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM OOO - O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz OOO - O PCM L, C, R, SL, SR, LFE
PCM (Audio) Multi Channel Stereo OOOOO*PCM L, R
Analog Multi Channel Stereo OOOOO*ANALOG -
* : Depending on the particular setup, there may be differences compared to the information contained in
these tables.
O* : When L/R (FRONT Speaker) = SMALL.
SR4002-5002NDFU01E22.indd35 07.7.1811:45:44AM
The relation between the selected surround mode and the input signal
The surround mode is selected with the surround mode buttons on SR5002 or the remote control unit. However, the sound
you hear is subject to the relationship between the selected surround mode and input signal. That relationship is as follows;
