Marantz SR5002N1B - Page 112

134
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
SEL/ENC C871 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
SEL/ENC C872 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
SEL/ENC C873 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
SEL/ENC CN82 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
SEL/ENC CN86 ns
p
ns
p
CONN. 11P WAFER STRAIGHT CJP11GA19ZY
SEL/ENC D801 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
SEL/ENC EN82 90M-SR000270R 90M-SR000270R ROTARY SW EC16B12S0AD4ZZZ HSR2A032Z
SEL/ENC J802 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SEL/ENC J803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SEL/ENC J811 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SEL/ENC J835 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SEL/ENC J866 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
SEL/ENC JW14 ns
p
ns
p
CORD WIRE ASSY CWE8202150RV
SEL/ENC Q802 00MBA10001000 00MBA10001000 TRS. KRA102M HVTKRA102MT
SEL/ENC R837 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
SEL/ENC R871 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SEL/ENC R872 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SEL/ENC R873 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SEL/ENC R874 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
SEL/ENC R875 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681T
SEL/ENC R876 ns
p
ns
p
RES. 820 OHM 1/5W J CRD20TJ821T
SEL/ENC R877 ns
p
ns
p
RES. 560 OHM 1/5W J CRD20TJ561T
SEL/ENC R879 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681T
SEL/ENC SW94 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
SEL/ENC SW95 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
TACT SW PWB
TACT J822
/
U1B ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TACT J823
/
U1B ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TACT SW96
/
U1B ns
p
90M-SP001210R SW SKHV10910G TACT CST1A012ZT
TR BIAS PWB
(
CUP12000Z
)
TR BIAS C851 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C852 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C853 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C854 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C855 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C856 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS C857 ns
p
90M-OA000640R ELECT CAP. KRM 100V/10UF 5X11 CCEA2AH100TS
TR BIAS CN81 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN82 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN83 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN84 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN85 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN86 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS CN87 ns
p
ns
p
CONN. 2P ANGLE CJP02GB46ZY
TR BIAS Q851 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q852 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q853 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q854 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q855 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q856 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS Q857 90M-HT800120R 90M-HT800120R TRS. KTC3114A HVTKTC3114A
TR BIAS R874 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R875 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R876 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R877 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R878 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R879 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R880 ns
p
ns
p
RES. 330 OHM 1/4W CRG14SANCJ331T
TR BIAS R882 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R883 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R884 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R885 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R886 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R887 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS R888 ns
p
ns
p
RES. 1.2K OHM 1/4W CRG14SANCJ122T
TR BIAS VR81 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TR BIAS VR82 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
