135
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
TR BIAS VR83 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TR BIAS VR84 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TR BIAS VR85 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TR BIAS VR86 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TR BIAS VR87 90M-RA001100R 90M-RA001100R TRIM. RES. 220 OHM HVN1RA221B01T
TRANS. PWB
(
CUP11994Z-4
)
TRANS C921 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS C922 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS C923 ns
p
ns
p
FILM CAP. 0.12UF 100V J HCQI1H124JZT
TRANS C924 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS C925 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS C926 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS C927 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 100V J HCQI1H223JZT
TRANS C931 ns
p
ns
p
FILM CAP. 0.047UF 100V J HCQI1H473JZT
TRANS C932 ns
p
ns
p
FILM CAP. 0.047UF 100V J HCQI1H473JZT
TRANS CN20 ns
p
ns
p
CONN. 3P WAFER CJP03GA90ZY
TRANS CN93 ns
p
ns
p
CONN. STRAIGHT, 3PIN CJP03GA19ZY
TRANS D990 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
TRANS J838 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS J843 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS J950 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
TRANS R997 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS R998 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
TRANS RL81 90M-LY000440R 90M-LY000440R RELAY ! GB-2C-D24P CSL4B019ZU
VIDEO PWB
(
CUP11996Z
)
VIDEO C404 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C405 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C406 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C410 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C411 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C412 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C416 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C417 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C418 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C425 ns
p
00MDD95470300 CER. CAP. 47PF 50V JA CCUS1H470JA
VIDEO C426 ns
p
00MDD95470300 CER. CAP. 47PF 50V JA CCUS1H470JA
VIDEO C427 ns
p
00MDD95470300 CER. CAP. 47PF 50V JA CCUS1H470JA
VIDEO C428 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C429 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C430 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
VIDEO C434 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
VIDEO C435 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C436 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
VIDEO C437 ns
p
00MDD95680300 CER. CAP. 68PF 50V JA CCUS1H680JA
VIDEO C438 ns
p
00MDD95680300 CER. CAP. 68PF 50V JA CCUS1H680JA
VIDEO C439 ns
p
00MDD95680300 CER. CAP. 68PF 50V JA CCUS1H680JA
VIDEO C440 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C441 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
VIDEO C442 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C443 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C448 ns
p
00MDD95470300 CER. CAP. 47PF 50V JA CCUS1H470JA
VIDEO C459 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C460 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
VIDEO C464 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C465 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C466 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C467 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
VIDEO C468 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C469 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C470 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C471 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C472 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
VIDEO C473 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C474 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO C475 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C476 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
VIDEO C477 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
