70
IC11 : HD64F2506
pin
No
Port Name Mode7 I/O use STBY Name
Port Setting
Note
Act. init
62 P90/AN8 I,I AD AD MODEL_SEL - - Model Select
63 P47/AN7 I,I AD AD TV_AUTO - - TV Video Detect
64 P46/AN6 I,I I I MIC_IN L H MIC IN
65 P45/AN5 I,I AD AD VER_SEL - - VERSION SELECT
66 P44/AN4 I,I AD AD P_LINE_FAIL - - Emergency Protection
67 AVss I - I AVSS - - GND
68 P43/AN3 I,I AD AD _5V_DOWN - - Detect 5V
69 P42/AN2 I,I AD AD KEY2 - - Front Key
70 P41/AN1 I,I AD AD KEY1 - - Front Key
71 P40/AN0 I,I AD AD KEY0 - - Front Key
72 Vref I YES I VCC - - +5V'
73 AVcc I YES I AVCC - - +5V'
74 P50/TxD2 I/O,O SO SO DSPOUT DSP, DIR Control Data OUT
75 P51/RxD2 I/O,I SI SI DSPIN DSP, DIR Control Data IN
76 P52/SCK2 I/O,O SC SC DSPCLK DSP, DIR Control CLOCK
77 PF0/~IRQ2 I/O,I INT I RERR H - DIR ERROR
78 PF1/BUZZ I/O,O O I CP_SEL1 NJM2584 1/3
79 PF2 I/O O I CP_SEL2 NJM2584 2/3
80 PF3/~ADTRG/~IRQ3 I/O,I,I I I REQ1 L - DSP INTER Q
81 PF4 I/O I I REQ2 L - DSP FINTR EQ
82 PF5 I/O O I V_CONV_SEL NJM2586
83 PF6 I/O O I COMP_MUTE NJM2586
84 P1Vcc I YES I VCC - - +5V'
85 PF7/ I/O,O I I2CSEL/INT
86 Vss I - I VSS - - GND
87 TEST I NO I TEST - - GND
88 VCL I - I VCL - - GND (0.47uF)
89 OSC2 I NO I NC - - open
90 OSC1 I NO I VSS - - GND
91 NMI I NO I NMI - - Fix H
92 MD2 I YES I MD2 - - Nomal:H, Bool:L
93 XTAL I YES I XTAL - - Xtal(20MHz)
94 Vss I NO I VSS - - GND
95 EXTAL I YES I EXTAL - - Xtal(20MHz)
96 Vcc I YES I VCC - - +5V'
97 MD0 I YES I MD0 - - Fix H
98 MD1 I YES I MD1 - - Fix H
99 ~STBY I NO I _STBY L H Fix H
100 ~RES I YES I _RES L - RESET
101 P20/TIOCA3 I/O,I/O O I MV_CL BD3812F MultiVol
102 P21/TIOCB3 I/O,I/O O I MV_DA BD3812F MultiVol
103 P22/TIOCC3 I/O,I/O O I MV_SEL BD3812F MultiVol
104 P23/TIOCD3 I/O,I/O I I SPKC_SW - - Speaker C Switch
105 P24/TIOCA4 I/O,I/O O I SPKC_CONT C-Relay Control
106 P25/TIOCB4 I/O,I/O O I KILLFLASH Kill Flasher OUT
107 P26/TIOCA5 I/O,I/O T_OUT O RC_OUT L RC BUS OUT
108 P27/TIOCB5 I/O,I/O I I NC
109 P17/TIOCB2/TCLKD I/O,I/O,I/O I I NC
110 P16/TIOCA2/~IRQ1 I/O,I/O,I INT INT WAKEUP
↑
- Standby Mode Release
111 P15/TIOCB1/TCLKC I/O,I/O,I/O T_IN I VSYNC
↑
- V-sync Det. & Change OSD
112 P14/TIOCA1/~IRQ0 I/O,I/O,I INT I _P_DPWN L - Power Down Detect
113 P13/TIOCD0/TCLKB I/O,I/O,I/O O O KILLIR H L Kill to IR Input Signal
114 P12/TIOCC0/TCLKA I/O,I/O,I/O O I DC_OUT1 L H DC Triger1
115 P11/TIOCB0 I/O,I/O O I MV_MUTE BD3812F MultiVol
116 P10/TIOCA0 I/O,I/O T_IN I RC_IN
↑↓
- IR In for RC-5
117 Vss I YES I VSS - - GND
118 P2Vcc I YES I VCC - - +5V'
119 P37/TxD4 I/O,O SO O XM_TXD XM->
120 P36/RxD4 I/O,I SI I XM_RXD <-XM
121
P35/SCK1/SCK4/SCL0/
~IRQ5
I/O,I/O,I/
O,I/O,I
INT I HDMI_INT TX or RX or SCDT
122 P34/RxD1/SDA0 I/O,I,I/O I I HDMI_MUTE H L MUTE INPUT for HDMI
123 P33/TxD1/SCL1 I/O,O,I/O SC I V_SCL - - Video Conv CLK
124 P32/SCK0/SDA1/~IRQ4 I/O,I/O,I/O,I SIO I V_SDA - - Video Conv DATA
125 P31/RxD0 I/O,I SI I RXD
UART for RS232C, Flash WR
Pull UP
RESET : H
