FEATURES
 Sampling Rate Ranging from 8kHz to 192kHz
 128 times Oversampling (Normal Speed Mode)
 64 times Oversampling (Double Speed Mode)
 32 times Oversampling (Quad Speed Mode)
 24-Bit 8 times FIR Digital Filter
 SCF with High Tolerance to Clock Jitter
 2nd order Analog LPF
 Single Ended Output Buffer
 Digital de-emphasis for 32k, 44.1k and 48kHz sampling
 Soft mute
 Digital Attenuator (Linear 256 steps)

I/F format: 24-Bit MSB justified, 24/20/16-Bit LSB justified or I
2
S
 Master clock: 256fs, 384fs, 512fs, 768fs or 1152fs (Normal Speed Mode)
128fs, 192fs, 256fs or 384fs (Double Speed Mode)
128fs, 192fs (Quad Speed Mode)
 THD+N: -94dB
 Dynamic Range: 106dB
 Power supply: 4.5 to 5.5V
 Very Small Package: 16pin TSSOP (6.4mm x 5.0mm)
LRC
K
BIC
K
SDTI
Audio
Data
Interface
MCLK
PDN
'6
Modulator
AOUTL
8X
Interpolator
SCF
LPF
AOUTR
V
DD
V
SS
V
COM
De-emphasis
Control
P/S
μP
Interface
Clock
Divider
SMUTE/CSN
ACKS/CCL
K
DIF0/CDTI
'6
Modulator
8X
Interpolator
DZFR
DZFL
SCF
LPF
ATT
ATT
No. Pin Name I/O Function
1 MCLK I Master Clock Input Pin
An external TTL clock should be input on this pin.
2 BICK I Audio Serial Data Clock Pin
3 SDTI I Audio Serial Data Input Pin
4 LRCK I L/R Clock Pin
5 PDN I Power-Down Mode Pin
When at “L”, the AK4384 is in the power-down mode and is held in reset.
The AK4384 should always be reset upon power-up.
SMUTE I Soft Mute Pin in parallel mode
“H”: Enable, “L”: Disable
6
CSN I Chip Select Pin in serial mode
ACKS I Auto Setting Mode Pin in parallel mode
“L”: Manual Setting Mode, “H”: Auto Setting Mode
7
CCLK I Control Data Clock Pin in serial mode
DIF0 I Audio Data Interface Format Pin in parallel mode 8
CDTI I Control Data Input Pin in serial mode
9 P/S I
Parallel/Serial Select Pin (Internal pull-up pin)
“L”: Serial control mode, “H”: Parallel control mode
10 AOUTR O Rch Analog Output Pin
11 AOUTL O Lch Analog Output Pin
12 VCOM O Common Voltage Pin, VDD/2
Normally connected to VSS with a 0.1
P
F ceramic capacitor in parallel with a
10
P
F electrolytic cap.
13 VSS - Ground Pin
14 VDD - Power Supply Pin
15 DZFR O Rch Data Zero Input Detect Pin
16 DZFL O Lch Data Zero Input Detect Pin
Note: All input pins except pull-up pin should not be left floating.
IC52 :AK4384ET (SR5002/U only)
