Marantz SR5002N1B - Page 88

110
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT CN80 ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA117ZY
INPUT CN83 ns
p
ns
p
CONN. 9P STRAIGHT CJP09GA19ZY
INPUT CN89 ns
p
ns
p
CONN. 7P STRAIGHT CJP07GA19ZY
INPUT CN90 ns
p
ns
p
CONN. CARDCABLE CJP11GA117ZY
INPUT CN95 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
INPUT CN96
/
U1B ns
p
ns
p
CONN. STRAIGHT, 3PIN CJP03GA19ZY
INPUT CN97
/
U1B ns
p
ns
p
CONN. 15P CARD CABLE CJP15GA115ZY
INPUT CN98 ns
p
ns
p
CORD WIRE ASSY CJP11GA01ZY
INPUT CN99 ns
p
ns
p
CONN. 13P WAFER CARD CABLE CJP13GA117ZY
INPUT D301 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D303 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D304 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D305 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D306 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D309 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D310 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D311 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D313 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D314 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D315 90M-HD302410R 90M-HD302410R ZENER DIODE ZJ8.2BT CVDZJ8.2BT
INPUT D316 90M-HD302460R 90M-HD302460R ZENER DIODE ZJ5.6B 1/2W CVDZJ5.6BT
INPUT D317 90M-HD302460R 90M-HD302460R ZENER DIODE ZJ5.6B 1/2W CVDZJ5.6BT
INPUT D318 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D319 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D320 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D322 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D323 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D331 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
INPUT D332 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
INPUT D333 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
INPUT D334 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
INPUT D335 ns
p
90M-HD201820R DIODE RB160L-60TE25 HVDRB160L60TE25
INPUT D336 ns
p
90M-HD201820R DIODE RB160L-60TE25 HVDRB160L60TE25
INPUT D801
/
U1B ns
p
00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D802
/
N1B 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D802
/
N1S 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D803 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D804 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D807 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D808 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D809 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT D810 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
INPUT IC11 90M-HS32CW10R 90M-HS32CW10R U-PRO HD64F2505 SR4002 HVIHD64F2505
INPUT IC12
/
N1B 90M-HC108390R 90M-HC108390R IC AT24C08N10SC2.7 HVIAT24C08N10SC
INPUT IC12
/
N1S 90M-HC108390R 90M-HC108390R IC AT24C08N10SC2.7 HVIAT24C08N10SC
INPUT IC12
/
U1B ns
p
00MHC10476990 IC AT24C32AN-10SU-2.7 CVIAT24C32ANSU2
INPUT IC13 00MHC10099540 00MHC10099540 IC S-80145ALMC HVIS-80145ALMC
INPUT IC17 90M-HC109800R 90M-HC109800R IC R2S15205FP CVIR2S15205FP
INPUT IC20 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC21 90M-HC109850R 90M-HC109850R IC BD3812F CVIBD3812F
INPUT IC23 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC24 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC25 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC26 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC27 00MHC10021880 00MHC10021880 IC CS494003-CQ DECODER HVICS49400-CQ
INPUT IC28 00MHC10418030 00MHC10418030 IC LC89057W-VF4-E HVILC89057WVF4E
INPUT IC29 90M-HC110090R 90M-HC110090R IC CS42528-CQ HVICS42528-CQ
INPUT IC30 90M-HC400100R 90M-HC400100R IC M74HC4053RM13TR/SOP CVIM74HC4053RM13TR
INPUT IC31 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
INPUT IC34 90M-HC109290R 90M-HC109290R IC TC74VHC157FT HVITC74VHC157FT
INPUT IC35 90M-HC900150R 90M-HC900150R IC KIA1117S/F33 REGULATOR CVIKIA1117S33
INPUT IC36 90M-HC900180R 90M-HC900180R IC KIA1117S25-RTK/P CVIKIA1117S25
INPUT IC37 90M-HC108430R 90M-HC108430R IC TC74HC7007AFEL HVITC74HCT7007F
INPUT IC38 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC39 90M-HC108930R 90M-HC108930R IC 74LCX32 HVI74LCX32TTR
INPUT IC40 90M-HS32CW20R 90M-HS32CW20R UPRO M29W400DT70N SR4002 HVIM29W400DT70N
INPUT IC41 90M-HC108970R 90M-HC108970R IC HY57V161610ET-7 HVI57V161610ET7
