Marantz SR5002N1B - Page 89

111
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT IC42 00MHC10172090 00MHC10172090 IC NJM2115MD OP AMP HVINJM2115MDTE1
INPUT IC43 00MHC10172090 00MHC10172090 IC NJM2115MD OP AMP HVINJM2115MDTE1
INPUT IC44 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC45 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC46 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC47 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC48 00MHC007505K0 00MHC007505K0 IC TC74VHCT08FT HVITC74VHCT08FT
INPUT IC50
/
U1B ns
p
90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC51
/
U1B ns
p
00MHC007505K0 IC TC74VHCT08FT HVITC74VHCT08FT
INPUT IC52
/
U1B ns
p
90M-HC900190R IC KIA1117S50-RTK/P CVIKIA1117S50
INPUT JK11 90M-YT005330R 90M-YT005330R TERMINAL YKC22-0836V OPT+CINCH RX CJS9U013Z
INPUT JK12 90M-YT005330R 90M-YT005330R TERMINAL YKC22-0836V OPT+CINCH RX CJS9U013Z
INPUT JK13 90M-YT005030R 90M-YT005030R OPT. CONN. TORX177L HJSTORX177L
INPUT JK14 90M-YT005310R 90M-YT005310R OPT. CONN. TOTX177L HJSTOTX177L
INPUT JK31 90M-YT004050R 90M-YT004050R TERMINAL RCA-401DA-16 CJJ4P052Z
INPUT JK32 90M-YT005000R 90M-YT005000R TERMINAL CINCH 8P C/SUB/SBL/SBR CJJ4P059Z
INPUT JK34 90M-YT002960R 90M-YT002960R TERMINAL CINCH 6P AUDIO CJJ4R019Z
INPUT JK35 90M-YT002960R 90M-YT002960R TERMINAL CINCH 6P AUDIO CJJ4R019Z
INPUT JK36 90M-YT003230R 90M-YT003230R TERMINAL CINCH 4P AUDIO CJJ4P014Y
INPUT JK37 90M-YT003230R 90M-YT003230R TERMINAL CINCH 4P AUDIO CJJ4P014Y
INPUT L101 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L102 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L103 90M-FC900460R 90M-FC900460R EMI FILTER CHIP BEAD
(
EMC FILTER
)
CLZ9R007Z
INPUT L104 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L105 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L106 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L107 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L108 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L109 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L301 ns
p
ns
p
COIL 47UH HLQ02C470KT
INPUT L801 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L802
/
U1B ns
p
ns
p
COIL 10UH,K HLQ02C100KT
INPUT L811
/
U1B ns
p
90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT Q305 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q306 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q307 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q308 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q309 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q310 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q311 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q312 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q313 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q314 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q315 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q316 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q317 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q318 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q319 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q320 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q321 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q322 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q323 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q324 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q325 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q328 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q329 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q330 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q331 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q332 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q333 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q334 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q335 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q339 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q340 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q347 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
INPUT Q348 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
INPUT Q349 00MHF201171D0 00MHF201171D0 TRS. 2SK117-BL HVT2SK117-BL
