Example connection when using two sets of ceiling speakers
.
C
FL FR
SW
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 217)
.
FR FL C SR SL
SW
TRR TRLTRR TRLTFR TFLTFR TFL
HEIGHT 1
z
HEIGHT 2
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 52)
