Marantz SR6012 - Connecting 7.1-Channel Speakers

Connecting 7.1-channel speakers
o
Example connections when using surround back speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
.
FL
SW C
SL
FR
SR
SBRSBL
0
Set “Floor” - “Layout” to “5ch & SB” in the menu when connecting in this
configuration. (v
p. 204)
.
FR FL C SR SL
SW
SBR SBL
0
When using a single surround back speaker, connect it to the SURROUND BACK
L terminal.
