Marantz SR6200 N2B - Page 38

54
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R536SL nsp CHIP 470-J 1/16W-1608 nsp
R536SR nsp CHIP 470-J 1/16W-1608 nsp
R536S W nsp CHIP 470-J 1/16W-1608 nsp
R537
nsp CHIP 22K-J 1/16W-1608 nsp
R542
R543
nsp 100K-J 1/6W-52RE-AX nsp
R547
R549C nsp CHIP,100K-J 1/16W-1608 nsp
R549FL nsp CHIP,100K-J 1/16W-1608 nsp
R549FR nsp CHIP,100K-J 1/16W-1608 nsp
R549SC nsp CHIP,100K-J 1/16W-1608 nsp
R549SL nsp CHIP,100K-J 1/16W-1608 nsp
R549SR nsp CHIP,100K-J 1/16W-1608 nsp
R549S W nsp CHIP 1000K-J 1/16W-1608 nsp
R559C nsp CHIP 470-J 1/16W-1608 nsp
R559FL nsp CHIP 470-J 1/16W-1608 nsp
R559FR nsp CHIP 470-J 1/16W-1608 nsp
R559SC nsp 470-J 1/6W-52RE-AX nsp
R559SL nsp CHIP 470-J 1/16W-1608 nsp
R559SR nsp CHIP 470-J 1/16W-1608 nsp
R559S W nsp CHIP 470-J 1/16W-1608 nsp
R567C nsp CHIP 3K-J 1/16W-1608 nsp
R567FL nsp CHIP 3K-J 1/16W-1608 nsp
R567FR nsp CHIP 3K-J 1/16W-1608 nsp
R567SC nsp CHIP 3K-J 1/16W-1608 nsp
R567SL nsp CHIP 3K-J 1/16W-1608 nsp
R567SR nsp CHIP 3K-J 1/16W-1608 nsp
R567S W nsp CHIP 5.1K-J 1/16W-1608 nsp
R569C nsp CHIP 1.2K-J 1/16W-1608 nsp
R569FL nsp CHIP 1.2K-J 1/16W-1608 nsp
R569FR nsp CHIP 1.2K-J 1/16W-1608 nsp
R569SC nsp CHIP 1.2K-J 1/16W-1608 nsp
R569SL nsp CHIP 1.2K-J 1/16W-1608 nsp
R569SR nsp CHIP 1.2K-J 1/16W-1608 nsp
R569S W nsp CHIP 1.2K-J 1/16W-1608 nsp
R582C nsp CHIP,68K-J 1/16W-1608 nsp
R582FL nsp CHIP,68K-J 1/16W-1608 nsp
R582FR nsp CHIP,68K-J 1/16W-1608 nsp
R582SC nsp CHIP,68K-J 1/16W-1608 nsp
R582SL nsp CHIP,68K-J 1/16W-1608 nsp
R582SR nsp CHIP,68K-J 1/16W-1608 nsp
R582S W nsp CHIP,68K-J 1/16W-1608 nsp
R589C nsp CHIP 470-J 1/16W-1608 nsp
R589FL nsp CHIP 470-J 1/16W-1608 nsp
R589FR nsp CHIP 470-J 1/16W-1608 nsp
R589SC nsp CHIP 470-J 1/16W-1608 nsp
R589SL nsp CHIP 470-J 1/16W-1608 nsp
R589SR nsp CHIP 470-J 1/16W-1608 nsp
R589S W nsp CHIP 470-J 1/16W-1608 nsp
R590 nsp 1K-J 1/6W-52RE-AX nsp
R591 nsp CHIP 2K-J 1/16W-1608 nsp
R592 nsp 1K-J 1/6W-52RE-AX nsp
R593 nsp CHIP 2K-J 1/16W-1608 nsp
R594 nsp CHIP 2K-J 1/16W-1608 nsp
R595
nsp 1K-J 1/6W-52RE-AX nsp
R598
R599 nsp 100-J 1/6W-52RE-AX nsp
R600 nsp 100-J 1/6W-52RE-AX nsp
R601 nsp CHIP 100K-J 1/16W-1608 nsp
R602 nsp CHIP 100K-J 1/16W-1608 nsp
R603 nsp 4.7K-J 1/6W-52RE-AX nsp
R604 nsp 4.7K-J 1/6W-52RE-AX nsp
R605 nsp CHIP 4.7K-J 1/16W-1608 nsp
R606 nsp CHIP 4.7K-J 1/16W-1608 nsp
R607
nsp CHIP 10K-J 1/16W-1608 nsp
R612
R613 nsp CHIP 47K-J 1/16W-1608 nsp
R614 nsp CHIP 47K-J 1/16W-1608 nsp
R615
nsp CHIP 10K-J 1/16W-1608 nsp
R618
R619 nsp CHIP 100K-J 1/16W-1608 nsp
R620 nsp CHIP 100K-J 1/16W-1608 nsp
VOLUME - SEMICONDUCTORS
D501
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D512
IC501 9965 000 01373 IC KIC9459F/SOP24P HC10449050
IC502 9965 000 10985 IC KIC9482F /
6CH WITHOUT TONE FLP28
*HC107280R
IC505
4822 209 17155 IC NJM2068M-SOP8P HC10102090
IC509
IC512 4822 209 17155 IC NJM2068M-SOP8P HC10102090
IC513 4822 209 16843 IC NJU7313AL-SDIP28P HC10125090
IC514 9965 000 02111 IC BU4053BCF/SOP16P HC405321Z0
Q501
9965 000 10744 TRS.2SC KTC2875B 0.15W/
LOW-ON-RES SOT23(RTK)
*HT300870R
Q514
VOLUME - MISCELLANEOUS
CN114 nsp CN.WAFER 2.0MM
TUC-P15X-B1 BD-TO-BD
15P HOUSING ST (35237-15)
nsp
CN115 nsp CN.WAFER 2.0MM
TUC-P20X-B1 BD-TO-BD
20P HOUSING ST (35237-20)
nsp
CP503 nsp CN WIRE 220MM 12P
GILS-12 GILT-12
(CONECTOR CNT503)
nsp
R505 nsp JUMPER (0.6/52MM) nsp
R506 nsp JUMPER (0.6/52MM) nsp
SPEAKER CIRCUIT BOARD
SPEAKER - CAPACITORS
C903FC p FILM 0.0022 µ F-J/100V-5RE nsp
C903FL p FILM 0.0022 µ F-J/100V-5RE nsp
C903FR p FILM 0.0022 µ F-J/100V-5RE nsp
C903SC p FILM 0.0022 µ F-J/100V-5RE nsp
C903SL p FILM 0.0022 µ F-J/100V-5RE nsp
C903SR p FILM 0.0022 µ F-J/100V-5RE nsp
C904 FCG p CER. 0.0047 µ F-K/16V-52RE nsp
C904 FLG p CER. 0.0047 µ F-K/16V-52RE nsp
C904 FRG p CER. 0.0047 µ F-K/16V-52RE nsp
C904 SCG p CER. 0.0047 µ F-K/16V-52RE nsp
C904 SLG p CER. 0.0047 µ F-K/16V-52RE nsp
C904 SRG p CER. 0.0047 µ F-K/16V-52RE nsp
SPEAKER - MISCELLANEOUS
CN101 nsp CN.WAFER 2.5MM PLUG BD
52668-1317 13P 2.5 ANG ZIP
nsp
