Marantz SR6200 N2B - Page 39

55
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
FRONT CIRCUIT BOARD
FRONT - CAPACITORS
C301 nsp ELECT 47 µ F-M/10V 5*11-5RE nsp
C302 nsp CER. F0.022 µ F-Z/25V-52RE nsp
C303 nsp CER. F0.047 µ F-Z/50V-52RE nsp
C304 nsp CER. B100pF-K/50V-52RE nsp
C305 nsp ELECT 10 µ F-M/50V 5*11-5RE nsp
C306 nsp CER. F0.047 µ F-Z/50V-52RE nsp
C307 nsp ELECT 10 µ F-M/50V 5*11-5RE nsp
C308 nsp CER. F0.022 µ F-Z/25V-52RE nsp
C309 nsp CER. B100pF-K/50V-52RE nsp
C310 nsp CER. F0.047 µ F-Z/50V-52RE nsp
C311 nsp CER. B100pF-K/50V-52RE nsp
C312 nsp CER. B100pF-K/50V-52RE nsp
C313 nsp ELECT 10 µ F-M/50V 5*11-5RE nsp
C314 nsp ELECT 10 µ F-M/50V 5*11-5RE nsp
C315 nsp CER. B820pF-K/50V-52RE nsp
C316 nsp CER. B820pF-K/50V-52RE nsp
C317 nsp ELECT 10 µ F-M/50V 5*11-5RE nsp
C318
nsp CER. B100pF-K/50V-52RE nsp
C321
C322 nsp CER. F0.1 µ F-Z/50V-52RE nsp
C323 nsp CER. F0.1 µ F-Z/50V-52RE nsp
C371 nsp CER. B820pF-K/50V-52RE nsp
C372 nsp CER. B820pF-K/50V-52RE nsp
CN301 nsp CN WIRE 450/9P 9073-9=GILS-
3 2 4 WH2547#26+BK1533#26
nsp
CN303 nsp CN WIRE 100MM/4P
9073-04=9073-04 WH1007#26
nsp
CN304 nsp CN WIRE 470MM/5P
GILS-5=9073-5 WH1007#26
nsp
CN305 nsp CN WIRE 80/3P
GILS-03=9073-03 RD1007#26
nsp
CP305 nsp CN.WAFER 2.0MM
GIL-S-03P-S2L2-EF
nsp
FRONT - RESISITORS
R301 nsp 68K-J 1/6W-52RE-AX nsp
R302 nsp 68K-J 1/6W-52RE-AX nsp
R303 nsp 330-J 1/6W-52RE-AX nsp
R304 nsp 100-J 1/6W-52RE-AX nsp
R305 nsp 120-J 1/6W-52RE-AX nsp
R306 nsp 150-J 1/6W-52RE-AX nsp
R307 nsp 150-J 1/6W-52RE-AX nsp
R308 nsp 270-J 1/6W-52RE-AX nsp
R309 nsp 270-J 1/6W-52RE-AX nsp
R310 nsp 470-J 1/6W-52RE-AX nsp
R311 nsp 820-J 1/6W-52RE-AX nsp
R312 nsp 1K-J 1/6W-52RE-AX nsp
R313 nsp 120-J 1/6W-52RE-AX nsp
R314 nsp 150-J 1/6W-52RE-AX nsp
R315 nsp 150-J 1/6W-52RE-AX nsp
R316 nsp 270-J 1/6W-52RE-AX nsp
R317 nsp 270-J 1/6W-52RE-AX nsp
R318 nsp 470-J 1/6W-52RE-AX nsp
R319 nsp 820-J 1/6W-52RE-AX nsp
R322 nsp 1K-J 1/6W-52RE-AX nsp
R323 nsp 120-J 1/6W-52RE-AX nsp
R324 nsp 150-J 1/6W-52RE-AX nsp
R325 nsp 150-J 1/6W-52RE-AX nsp
R326 nsp 270-J 1/6W-52RE-AX nsp
R327 nsp 270-J 1/6W-52RE-AX nsp
R328 nsp 470-J 1/6W-52RE-AX nsp
R329 nsp 820-J 1/6W-52RE-AX nsp
R330 nsp 1.5K-J 1/6W-52RE-AX nsp
R332 nsp 1K-J 1/6W-52RE-AX nsp
R333 nsp 10K-J 1/6W-52RE-AX nsp
R334
nsp 1K-J 1/6W-52RE-AX nsp
R338
R340 nsp 330-J 1/6W-52RE-AX nsp
R341 nsp 330-J 1/6W-52RE-AX nsp
R342 nsp 47K-J 1/6W-52RE-AX nsp
R343 nsp 75-J 1/6W-52RE-AX nsp
R344 nsp 75-J 1/6W-52RE-AX nsp
R345 nsp 75-J 1/6W-52RE-AX nsp
R346 nsp 47K-J 1/6W-52RE-AX nsp
R347 nsp 470-J 1/6W-52RE-AX nsp
R348 nsp 100K-J 1/6W-52RE-AX nsp
R349 nsp 10K-J 1/6W-52RE-AX nsp
R350 nsp 100K-J 1/6W-52RE-AX nsp
R351 nsp 47K-J 1/6W-52RE-AX nsp
R352 nsp 470-J 1/6W-52RE-AX nsp
R353 nsp 2.2K-J 1/6W-52RE-AX nsp
R354 nsp 330-J 1/6W-52RE-AX nsp
R356 nsp 24K-J 1/6W-52RE-AX nsp
R357 nsp 24K-J 1/6W-52RE-AX nsp
R359 nsp 24K-J 1/6W-52RE-AX nsp
FRONT - SEMICONDUCTORS
D301 4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D317 4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D318 4822 130 10854 LED SLR-34URCF25 *HI100710R
D319 4822 130 10854 LED SLR-34URCF25 *HI100710R
D320 4822 130 10854 LED SLR-34URCF25 *HI100710R
D328 4822 130 83172 D ZENER MTZJ11B-0.5W/
5MA-52MM
*HD301990R
D332
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D337
FPC109B nsp CN.FP1.25MM 52492-2320 23P
BOTTOM ENTRY(CN109)
nsp
IC301 9965 000 10986 IC LC75721E / QIP64 DRIVER *HC107290R
L302 nsp COIL FILTER-INDUCTOR
10
µ H-Q40/24M-R2.5-52RE02TB
nsp
Q301 9965 000 10444 TRS. NPN RC KRC107M 0.4W/
TO92M
*BA001190R
Q302 9965 000 10987 TRS. PNP RA KRA111M 0.4W/
TO92M
*BA001200R
Q304 9965 000 10444 TRS. NPN RC KRC107M 0.4W/
TO92M
*BA001190R
Q305 9965 000 10444 TRS. NPN RC KRC107M 0.4W/
TO92M
*BA001190R
Q306 9965 000 10444 TRS. NPN RC KRC107M 0.4W/
TO92M
*BA001190R
Q309 4822 130 43233 TRS.2SC KTC3200BL 0.6W/
TO92
HT322402A0
FRONT-MISCELLANEOUS
SILD nsp SUPPORTER SR7200/
U2B(MARANTZ) SPTE 0.2t /
FRONT GND
nsp
SW301
9965 000 10988 SW TACT SKHV10920A
5MM/260G
*SP000900R
SW324
INPUT1 CIRCUIT BOARD
INPUT1-CAPACITORS
C417
K nsp CER. B100pF-K/50V-52RE nsp
C432
