65
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q208L
4822 130 43012 TRS.2SA KTA1024Y 1W/TO92L HT112082A0
Q208R
4822 130 43012 TRS.2SA KTA1024Y 1W/TO92L HT112082A0
Q208SC
4822 130 43012 TRS.2SA KTA1024Y 1W/TO92L HT112082A0
Q208SL
4822 130 43012 TRS.2SA KTA1024Y 1W/TO92L HT112082A0
Q208SR
4822 130 43012 TRS.2SA KTA1024Y 1W/TO92L HT112082A0
Q209C
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q209L
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q209R
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q209SC
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q209SL
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q209SR
4822 130 43225 TRS.2SC KTC3206Y 1W/TO92L HT322292A0
Q215C
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
Q215L
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
Q215R
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
Q215SC
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
Q215SL
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
Q215SR
9965 000 10750 TRS.2SC KSC1845F 0.5W/
TO92
*HT300860R
AMP - MISCELLANEOUS
CP201
nsp CN.WAFER 2.0MM
GIL-S-12P-S2T2-EF
nsp
CP202
nsp CN WIRE 80MM/
9P 5264-09=5395-09
RD1007#20 2.5MM
nsp
CP203
nsp CN WIRE 80MM/
10P 5264-10=5395-10
RD1007#20 2.5MM
nsp
L201C
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
L201L
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
L201R
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
L201SC
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
L201SL
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
L201SR
9965 000 10748 COIL FILTER-INDUCTOR
J9000031
*LC106490R
MAIN CIRCUIT BOARD
MAIN - CAPACITORS
C101
nsp FILM 0.1
µ
F-K/250V-5RE nsp
C102
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C103
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C104C
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C104FL
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C104FR
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C104SC
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C104SL
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C104SR
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105C
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105FL
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105FR
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105SC
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105SL
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C105SR
nsp FILM 0.1
µ
F-K/63V-5RE nsp
C106
nsp FILM 0.1
µ
F-K/250V-5RE nsp
C107
nsp FILM 0.1
µ
F-K/250V-5RE nsp
C108
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C111
C114
4822 124 11583 ELECT 2200
µ
F-M/35V 16*32 EA22803510
C115
4822 124 11583 ELECT 2200
µ
F-M/35V 16*32 EA22803510
C116
nsp CER. 0.01
µ
F-K/50V-5RE nsp
C117
nsp ELECT 10000
µ
F-M/16V
18*35L.BLK SY
nsp
C118
nsp ELECT 2200
µ
F-M/16V 12.5*20 nsp
C119
SR5200 9965 000 11011 ELECT 10000
µ
F-M/63V
30*50 DL-BLK SH
*OA000050R
C119
SR6200 9965 000 11062 ELECT 15000
µ
F-M/71V
(DL) 40*80
*EA001110R
C120
SR5200 9965 000 11011 ELECT 10000
µ
F-M/63V
30*50 DL-BLK SH
*OA000050R
C120
SR6200 9965 000 11062 ELECT 15000
µ
F-M/71V
(DL) 40*80
*EA001110R
C121
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C122
nsp FILM 0.1
µ
F-K/250V-5RE nsp
C123
nsp FILM 0.1
µ
F-K/250V-5RE nsp
C124
nsp CER. 0.01
µ
F-K/50V-5RE nsp
C125
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C129
C132
nsp ELECT 100
µ
F-M/25V
6.3*11-5RE.SY
nsp
C135
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C140
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C141
nsp ELECT 220
µ
F-M/25V 8*11.5-5 nsp
C142
nsp ELECT 220
µ
F-M/25V 8*11.5-5 nsp
C143
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C144
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C145
9965 000 11012 ELECT 10
µ
F-M/100V
6.3*11-5RE
*EA001080R
C147
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C148
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C149
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C150
nsp ELECT 47
µ
F-M/16V 5*11-5RE nsp
C151
9965 000 11013 ELECT 8200
µ
F-M/5.5V SY *EX000080R
C152
nsp CER. B100pF-K/50V-52RE nsp
C153
N p CER. F0.1
µ
F-Z/50V-52RE nsp
C154
N p CER. CH27pF-J/50V-5RE nsp
C155
N p CER. CH27pF-J/50V-5RE nsp
C156
N nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C157
N p CER. B270pF-K/50V-52RE nsp
C158
N nsp ELECT 47
µ
F-M/16V 5*11-5RE nsp
C159
N nsp CER. F0.1
µ
F-Z/50V-5RE PI6 nsp
C160
nsp CER. B100pF-K/50V-52RE nsp
C163
C164
nsp CER. B220pF-K/50V-52RE nsp
C164
nsp CER. B100pF-K/50V-52RE nsp
C165
nsp CER. B0.001
µ
F-K/50V-52RE nsp
C168
nsp CER. SL10pF-J/50V-52RE nsp
C169
nsp CER. F0.047
µ
F-Z/50V-52RE nsp
C173
C174
nsp ELECT 220
µ
F-M/25V
8*11.5-5RE
ns p
C175
nsp CER. SL47pF-J/50V-52RE nsp
C176
nsp CER. SL10pF-J/50V-52RE nsp
MAIN - RESISTORS
R101
9965 000 11024 0.22-J 1W-R. *GA000200R
R104
R105C
4822 053 11109 10-J 2W-52RE-AX GA05100020
R105FL
4822 053 11109 10-J 2W-52RE-AX GA05100020
R105FR
4822 053 11109 10-J 2W-52RE-AX GA05100020
R105SC
4822 053 11109 10-J 2W-52RE-AX GA05100020
R105SL
4822 053 11109 10-J 2W-52RE-AX GA05100020
R105SR
4822 053 11109 10-J 2W-52RE-AX GA05100020
R107
nsp 2.7K-J 1/6W-52RE-AX nsp
R108
nsp 2.7K-J 1/6W-52RE-AX nsp
R109
nsp 560K-J 1/6W-52RE-AX nsp
R110
nsp 3.6K-J 1/6W-52RE-AX nsp
R111
nsp 22K-J 1/6W-52RE-AX nsp
ns
ns
ns
ns
