66
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R112 nsp 910-J 1/6W-52RE-AX nsp
R113 nsp 470-J 1/6W-52RE-AX nsp
R114 9965 000 11021 R CEMENT MPR 0.1-J/5W
W14*H17
*GO000011R
R115 9965 000 11021 R CEMENT MPR 0.1-J/5W
W14*H17
*GO000011R
R116 nsp 27K-J 1/6W-52RE-AX nsp
R117 nsp 27K-J 1/6W-52RE-AX nsp
R118 nsp 7.5K-J 1/6W-52RE-AX nsp
R119 nsp 7.5K-J 1/6W-52RE-AX nsp
R120 nsp 560K-J 1/6W-52RE-AX nsp
R122
nsp 27K-J 1/6W-52RE-AX nsp
R127
R128 nsp 51K-J 1/6W-52RE-AX nsp
R129 nsp 51K-J 1/6W-52RE-AX nsp
R130 nsp 15K-J 1/6W-52RE-AX nsp
R131 nsp 33K-J 1/6W-52RE-AX nsp
R133 nsp 2.2K-J 1/6W-52RE-AX nsp
R134 nsp 100K-J 1/6W-52RE-AX nsp
R137
nsp 22K-J 1/6W-52RE-AX nsp
R142
R143 nsp 3.3K-J 1/6W-52RE-AX nsp
R144 nsp 15K-J 1/6W-52RE-AX nsp
R146 nsp 1.2K-J 1W-5 nsp
R147 nsp 22K-J 1/6W-52RE-AX nsp
R148 nsp 22K-J 1/6W-52RE-AX nsp
R150 nsp 18K-J 1/6W-52RE-AX nsp
R152 nsp 1.2K-J 1W-5 nsp
R154 nsp 1.2K-J 1W-5 nsp
R155 nsp 4.7K-J 1/6W-52RE-AX nsp
R157 nsp 100K-J 1/6W-52RE-AX nsp
R158 nsp 100K-J 1/6W-52RE-AX nsp
R159 nsp 1K-J 1/6W-52RE-AX nsp
R161 nsp 1M-J 1/6W-52RE-AX nsp
R162 nsp 47K-J 1/6W-52RE-AX nsp
R165 nsp 10K-J 1/6W-52RE-AX nsp
R166 nsp 47K-J 1/6W-52RE-AX nsp
R168 nsp 47K-J 1/6W-52RE-AX nsp
R169 nsp 220-J 1/6W-52RE-AX nsp
R170 nsp 100K-J 1/6W-52RE-AX nsp
R172 K p 10K-J 1/6W-52RE-AX nsp
R173 K.U p 15K-J 1/6W-52RE-AX nsp
R173 N p 4.7K-J 1/6W-52RE-AX nsp
R174 nsp 47K-J 1/6W-52RE-AX nsp
R175 nsp 10K-J 1/6W-52RE-AX nsp
R176 nsp 15K-J 1/6W-52RE-AX nsp
R177 nsp 470K-J 1/6W-52RE-AX nsp
R178 nsp 100-J 1/6W-52RE-AX nsp
R179 nsp 47K-J 1/6W-52RE-AX nsp
R181 nsp 10K-J 1/6W-52RE-AX nsp
R182 N p 2.2M-J 1/5W-52RE-AX nsp
R183 K p 47K-J 1/6W-52RE-AX nsp
R184 nsp 10K-J 1/6W-52RE-AX nsp
R185 nsp 100K-J 1/6W-52RE-AX nsp
R186 nsp 100K-J 1/6W-52RE-AX nsp
R187 N p 47K-J 1/6W-52RE-AX nsp
R188 N p 47K-J 1/6W-52RE-AX nsp
R189 nsp 10K-J 1/6W-52RE-AX nsp
R190 nsp 10K-J 1/6W-52RE-AX nsp
R191 N p 560-J 1/6W-52RE-AX nsp
R192 nsp 47K-J 1/6W-52RE-AX nsp
R193 nsp 3.3-J 1W-52RE-AX nsp
R194
nsp 10K-J 1/6W-52RE-AX nsp
R198
R199 nsp 1K-J 1/6W-52RE-AX nsp
R200 nsp 47K-J 1/6W-52RE-AX nsp
R201 nsp 47K-J 1/6W-52RE-AX nsp
R202 nsp 100-J 1/4W-R. nsp
R203 nsp 10K-J 1/6W-52RE-AX nsp
R204 nsp 47K-J 1/6W-52RE-AX nsp
MAIN - SEMICONDUCTORS
D101
9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
D105
D106 9965 000 11015 D RECTIFIER BRIDGE
KBPC604 6A
*HE200300R
D107 9965 000 11015 D RECTIFIER BRIDGE
KBPC604 6A
*HE200300R
D108 9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
D109 9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
D110 4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D111 9965 000 10728 DIODE IN4007 1000V 1A *HD201570R
D112
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D129
IC101 4822 209 91033 IC KA7815 /
IL7815CV 16W-TO220
*HC300150R
IC102 9965 000 11016 IC KIA7915PI
20W-TO220IS MOLD
*HC300200R
IC103 4822 209 90086 IC KA7805 *HC300140R
IC104 4822 209 90086 IC KA7805 *HC300140R
IC105 9965 000 11017 IC KIA7905PI
20W-TO220IS MOLD
*HC300190R
IC107 9965 000 11018 MICRO PROCESSOR
CXP740010-141Q QFP100
DWP572B /SR5200/6200
*HU100540R
IC108 N 4822 209 15824 IC TDA7330BD-SOP20P /
RDS DEMODULATOR
*HC107330R
J169 4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
J170 4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
Q101 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
Q102 4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q103 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
Q104 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
Q105 4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q106 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
Q107 4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q108 9965 000 10444 TRS. NPN RC KRC107M
0.4W/TO92M
*BA001190R
Q113 9965 000 10444 TRS. NPN RC KRC107M
0.4W/TO92M
*BA001190R
Q115 4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q116 4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q117 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
Q118 9965 000 10740 TRS.2SA KTA1268BL
0.3W/TO92
*HT100340R
