67
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q119
4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q120
4822 130 43233 TRS.2SC KTC3200BL
0.6W/TO92
HT322402A0
Q122
4822 130 61227 TRS. PNP RA KRA102M
0.3W/TO92M
*BA001210R
Q123
4822 130 60588 TRS. NPN RC KRC102M
0.4W/TO92M
*BA001180R
Q124
4822 130 61227 TRS. PNP RA KRA102M
0.3W/TO92M
*BA001210R
Q128
4822 130 61227 TRS. PNP RA KRA102M
0.3W/TO92M
*BA001210R
Q129
4822 130 60588 TRS. NPN RC KRC102M
0.4W/TO92M
*BA001180R
Q130
9965 000 10444 TRS. NPN RC KRC107M
0.4W/TO92M
*BA001190R
Q131
4822 130 61227 TRS. PNP RA KRA102M
0.3W/TO92M
*BA001210R
Q135
Q136
9965 000 10749 TRS.2SA KSA992F 0.5W/TO92 *HT100590R
Q213C
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q213FL
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q213FR
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q213SL
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q213SR
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q213SC
9965 000 11019 TRS.2SB SAP16P 150W
LF550(5P) POWER Tr.
*HT200410R
Q214C
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
Q214SR
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
Q214SL
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
Q214FR
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
Q214FL
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
Q214SC
9965 000 11020 TRS.2SD SAP16N 150W
LF550(5P) POWER Tr.
*HT400480R
MAIN - MISCELLANEOUS
BEAD101
nsp BEAD COIL BAS3580T0
3.5PHI*8 52RE
nsp
BEAD105
CNT108
nsp CN WIRE 420MM/4P
GIL-S-4=9073-4 WH1007#26
nsp
CP101
nsp CN.WAFER 2.5MM PLUG BD
53421-1317 13P 2.5 ST ZIP
nsp
CP103
nsp CN.WAFER 2.0MM
TUC-P09P-B1 BD-TO-BD
9P WAFER ST (35336-09)
nsp
CP104
nsp CN.WAFER 2.0MM
35336-1310 13P
nsp
CP105
nsp CN.WAFER 2.0MM
TUC-P09P-B1 BD-TO-BD
9P WAFER ST (35336-09)
nsp
CP106
nsp CN.WAFER 2.0MM
TUC-P15P-B1 BD-TO-BD
15P WAFER ST (35336-15)
nsp
CP107
nsp CN.WAFER 2.0MM
TUC-P10P-B1 BD-TO-BD
10P WAFER ST (35336-10)
nsp
CP108
nsp CN.WAFER 2.0MM
TUC-P20P-B1 BD-TO-BD
20P WAFER ST (35336-20)
nsp
CP109
nsp CN.WAFER 2.0MM
TUC-P04P-B1 BD-TO-BD
4P WAFER ST (35336-04)
nsp
CP110
nsp CN.WAFER 2.0MM
TUC-P11P-B1 BD-TO-BD
11P WAFER ST (35336-11)
nsp
CP111
nsp CN.WAFER 2.0MM
TUC-P10P-B1 BD-TO-BD
10P WAFER ST (35336-10)
nsp
CP112
nsp CN.WAFER 2.0MM
TUC-P15P-B1 BD-TO-BD
15P WAFER ST (35336-15)
nsp
CP113
nsp CN.WAFER 2.0MM
TUC-P18P-B1 BD-TO-BD
18P WAFER ST (35336-18)
nsp
CP114
nsp CN.WAFER 2.0MM
TUC-P15P-B1 BD-TO-BD
15P WAFER ST (35336-15)
nsp
CP115
nsp CN.WAFER 2.0MM
TUC-P20P-B1 BD-TO-BD
20P WAFER ST (35336-20)
nsp
CP116
nsp CN.WAFER 2.0MM
35336-1310 13P
nsp
CP120
nsp CN.WAFER 2.5MM5267-06A 6P nsp
CP121
nsp CN.WAFER 3.96MM35328-0310 nsp
CP122
nsp CN.WAFER 2.5MM5267-04A 4P nsp
CP123
nsp CN.WAFER 2.5MM
5267-10A 10P
nsp
CP124
nsp CN.WAFER 2.5MM5267-09A 9P nsp
CP150
nsp CN WIRE 200MM/2P
5264-02=51088-02 RD1007#22
nsp
FPC109
9965 000 11014 CABLE FLAT CARD FPC 23P
CN109 & FPC109A
*YU000930R
FPC109A
nsp CN.FP1.25MM
52045-2345 23P ST
nsp
GND101
nsp TERMINAL GND PLATE nsp
GND105
RLY102
9965 000 05895 RELAY G5PA-28 24V 5A LY20240490
RLY104
9965 000 11022 RELAY RSB24S
24V 2A30VDC/SMALL SIGNAL
*LY000290R
XTAL101
9965 000 11023 RESONATOR CER.
CST12.0MTW-TF01/
CSTLA12M0T55-A0
*FQ000530R
XTAL102
N 9965 000 11025 CRYSTAL 4.332MHZ HC49U
CL=30pF 30PPM ESR=60-5
*JX000800R
ZD121
4822 130 80317 D ZENER
MTZJ5.1B-0.5W/5MA-52MM
HD30511000
ZD122
4822 130 80317 D ZENER
MTZJ5.1B-0.5W/5MA-52MM
HD30511000
ZD129
N 4822 130 80317 D ZENER
MTZJ5.1B-0.5W/5MA-52MM
HD30511000
POWER CIRCUIT BOARD
POWER - CAPACITORS
C710
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C711
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C712
nsp FILM 0.047
µ
F-J/100V-5RE nsp
C713
nsp CER. F0.1
µ
F-Z/50V-5RE PI6 nsp
C714
nsp CER. AC(SAFETY)
DE2F3KH108MN4A
(DE1310-469E472M) P10 25
nsp
C717
nsp ELECT 470
µ
F-M/25V 10*12.5 nsp
C718
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C719
nsp ELECT 220
µ
F-M/50V 10*12.5 nsp
