Marantz SR7500/A1B - Page 119

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
142
SR7500 / PS7500
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
STANDBY PCB
(
CUP11764-2
)
ST-BY BK81ns
p
ns
p
BRACKET CMD1A387
ST-BY BK82ns
p
ns
p
BRACKET CMD1A387
ST-BY C881ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C882ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V HCEA1HH4R7
T
ST-BY C883ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101
T
ST-BY C884ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C885ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C886ns
p
00MOA33802520 ELECT CAP. 3300UF 25V HCEA1EH332E
ST-BY C887ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KB
T
ST-BY C888 90M-DK100810
R
90M-DK100810
R
CER. CAP. DE1610-610F103M BCKWKH103MF
ST-BY CN90 ns
p
ns
p
JACK KJP05GB99ZM
ST-BY CN91
/
A1B ns
p
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
A1S ns
p
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
F1N ns
p
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
K1G ns
p
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1B 90M-YP100250
R
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1G 90M-YP100250
R
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1S 90M-YP100250
R
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN92 90M-YP100250
R
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY CN93 90M-YP100250
R
90M-YP100250
R
JACK MOLEX35328-02 KJP02GA89ZM
ST-BY D802 ns
p
00MHD2001521
0
DIODE 1SS133T-77 HVD1SS133M
T
ST-BY D803 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY D804 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D805 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY D806 00MHD3082100
0
00MHD3082100
0
ZENER DIODE 8.2V 1/2
W
HVDMTZJ8.2BT
ST-BY D807 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D808 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D809 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D810 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D811 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D812 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY D813 ns
p
90M-HD201750
R
DIODE 1N4003 KVD1N4003SR
T
ST-BY F801 ns
p
ns
p
FUSE HOLDER KJCFC5S
ST-BY F802
/
F1N ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY F802
/
L1G ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY F802
/
U1B ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
F1N ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
L1G ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
N1B 90M-FS001070R 90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
N1G 90M-FS001070R 90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
N1S 90M-FS001070R 90M-FS001070R FUSE KBA2D2500TLET
ST-BY F803
/
U1B ns
p
90M-FS001070R FUSE KBA2D2500TLET
ST-BY IC84 90M-HC108410
R
90M-HC108410
R
IC S-80842CNY-
X
HVIS-80842CNY-
X
ST-BY IC85 90M-HC300500
R
90M-HC300500
R
IC REG KA7805-ABTU HVIMC7805C
ST-BY J828 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J829 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J830 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J831
/
L1G ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J831
/
U1B ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J834 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J889
/
N1B ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J889
/
N1G ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY J889
/
N1S ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
ST-BY JK85
/
F1N ns
p
90M-YT002410R TERMINAL A204D0041P KJJ7A015Z
ST-BY JK85
/
L1G ns
p
90M-YT002410R TERMINAL A204D0041P KJJ7A015Z
ST-BY JK85
/
U1B ns
p
90M-YT002410R TERMINAL A204D0041P KJJ7A015Z
ST-BY JK86
/
N1B 90M-YT002430R 90M-YT002430R TERMINAL A302D0061P KJJ7A022Z
ST-BY JK86
/
N1G 90M-YT002430R 90M-YT002430R TERMINAL A302D0061P KJJ7A022Z
ST-BY JK86
/
N1S 90M-YT002430R 90M-YT002430R TERMINAL A302D0061P KJJ7A022Z
ST-BY L801 00MLY1009001
0
00MLY1009001
0
RELAY SDT-S-109DM
R
HSL1D016ZE
ST-BY Q804 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102M
T
ST-BY Q805 90M-HT600040
R
90M-HT600040
R
TRS. HVTKTA1267YT
ST-BY R881ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
ST-BY R882ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
ST-BY R883ns
p
ns
p
RES. 2.2K OHM 1/5W J CRD20TJ222
T
