NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
143
SR7500 / PS7500
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
ST-BY R885ns
p
ns
p
RES. 1 OHM 1/5W J CRD20TJ1R0
T
ST-BY R886
/
U1B ns
p
90M-GG000010R RES. 3.3M OHM 1/2
W
BRDERC12UGK335
T
ST-BY R887ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
ST-BY R888 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
ST-BY T801
/
A1B ns
p
90M-TS002400R TRANSF. SR5500 SUBTRANS CLT5I002ZW
ST-BY T801
/
A1S ns
p
90M-TS002400R TRANSF. SR5500 SUBTRANS CLT5I002ZW
ST-BY T801
/
F1N ns
p
90M-TS001960R TRANSF. PS5400
(
6400
)
/F1 CLT5I002ZJ
ST-BY T801
/
K1G ns
p
90M-TS001950R TRANSF. SR5400
(
6400
)
/K1 CLT5I002ZH
ST-BY T801
/
L1G ns
p
90M-TS002090R TRANSF. SR5400
(
6400
)
/L1 CLT5I002ZS
ST-BY T801
/
N1B 90M-TS001940R 90M-TS001940R TRANSF. SR5400
(
6400
)
/N1 CLT5I002ZE
ST-BY T801
/
N1G 90M-TS001940R 90M-TS001940R TRANSF. SR5400
(
6400
)
/N1 CLT5I002ZE
ST-BY T801
/
N1S 90M-TS001940R 90M-TS001940R TRANSF. SR5400
(
6400
)
/N1 CLT5I002ZE
ST-BY T801
/
U1B ns
p
90M-TS001970R TRANSF. SR5400
(
6400
)
/U1 CLT5I002ZU
TUNER PCB
(
CUP11764-5
)
TUNER C397
/
F1N ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TUNER C398
/
F1N ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
TUNER CN32
/
F1N ns
p
ns
p
JACK KJP03GA19ZM
TUNER JK27
/
F1N ns
p
90M-YT003180R TERMINAL JACK , BOARD CJJ4N063Z
TUNER R394
/
F1N ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
TUNER R395
/
F1N ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
TUNER R396
/
F1N ns
p
ns
p
RES. 82K OHM 1/5W J CRD20TJ823
T
TUNER R397
/
F1N ns
p
ns
p
RES. 82K OHM 1/5W J CRD20TJ823
T
VIDEO PCB
(
CUP11763-2
)
VIDEO C702 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C704 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C706 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C707 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C708 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C710 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C711 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C712 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C713 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C714 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C715 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C716 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C717 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C719 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C720 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C722 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C723 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C725 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C726 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C727 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C728 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C729 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C730 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C732 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C733 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C734 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C735 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C736 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C737 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C738 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C739 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471
T
VIDEO C740 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C741 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C742 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C743 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
VIDEO C744 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V HCEA1HH2R2
T
VIDEO C745 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C746 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C747 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
VIDEO C748 ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
VIDEO C749 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101
T
VIDEO C751 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V HCEA1HH4R7
T
VIDEO C752 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
