Marantz SR8012 - Page 58

o
Example connection when using one set of Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
0
Set “Height” - “Dolby Sp” to “2ch” in the menu when connecting in this
configuration. (v
p. 214)
.
ASSIGNABLE ASSIGNABLE
SPEAKERS
CENTER SURROUND SURROUND BACK SURROUNDFRONT SURROUND BACK FRONT
FDR FDL
HEIGHT 1
z
SW
SBR SBL
FR FL C SR SL
z
The surround Dolby speakers can be connected instead of the front Dolby
speakers. In this case, set the Dolby Atmos Enabled speakers to be connected
under “Height” - “Layout” in the menu. (v p. 215)
Contents
Connections Playback Settings Tips Appendix
58
Front panel Display Rear panel Remote Index
