Example connection when using two sets of height speakers
.
C
FL FR
SBL
SBR
SW
SL SR
FHL FHR
RHL RHR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 214)
.
ASSIGNABLE ASSIGNABLE ASSIGNABLE
SPEAKERS
CENTER SURROUND
SURROUND BACK
SURROUNDFRONT
SURROUND BACK
FRONT
SW
SBR SBLFR FL C SR SL
FHR FHL
HEIGHT 1
z
RHR RHL
HEIGHT 2
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 66)
