Example connections when using ceiling speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with ceiling speakers.
.
C
FL FR
SW
SL SR
TML TMR
.
FRONT FRONT
CENTER
SURROUND SURROUND
ASSIGNABLE
ASSIGNABLE
ASSIGNABLE
SURROUND BACK
ASSIGNABLE
HEIGHT1 HEIGHT1
SPEAKERS
FR FL C SR SL
TMR TML
SW
0
Set “Floor” to “5ch” and “Height Sp” to “2ch” in the menu when connecting in this configuration. (v p. 234, 235)
0
The top front or top rear speakers can be connected instead of the top middle speakers. In this case, set the ceiling speakers to be connected under “Height” - “Layout” in the
menu. (v p. 236)
