Marantz SR8015 User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30° 30°
Approx. 7 m
Contents
Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Marantz SR8015 Specifications

General

Channels	11.2
Power Output	140 W (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	175 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	250 W
70% Guarantee	Yes
Total Harmonic Distortion	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
HDMI Inputs	8
HDMI Outputs	3
HDMI Version	2.1
8K/60Hz Pass-Through	Yes
4K/120Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Low Latency Mode (ALLM)	Yes
Variable Refresh Rate (VRR)	Yes
Quick Frame Transport (QFT)	Yes
Dolby Atmos	Yes
Dolby Atmos Height Virtualization	Yes
DTS:X	Yes
DTS Virtual:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
HEOS Built-in	Yes
AirPlay 2	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
USB Port	Yes
Phono Input	Yes
