Connecting a set-top box (Satellite tuner/cable TV)
This explanation uses the connection with a satellite tuner/cable TV STB as an example.
Select the input connectors on this unit to match the connectors on the device that you want to connect to.
.
R
L
R
L
OUT
COAXIAL
AUDIO
AUDIO
RL
OUT
OUT
VIDEO
VIDEO
OUT
HDMI
Satellite tuner/
Cable TV
(HDMI incompatible device)
or
Satellite tuner/
Cable TV
Contents
Connections Playback Settings Tips Appendix
90
Front panel Display Rear panel Remote Index

Other manuals for Marantz SR8015

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Marantz SR8015 and is the answer not in the manual?

Marantz SR8015 Specifications

General IconGeneral
Channels11.2
Power Output140 W (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)175 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)250 W
70% GuaranteeYes
Total Harmonic Distortion0.05%
Frequency Response10 Hz - 100 kHz
Input Sensitivity200 mV
Signal-to-Noise Ratio102 dB
HDMI Inputs8
HDMI Outputs3
HDMI Version2.1
8K/60Hz Pass-ThroughYes
4K/120Hz Pass-ThroughYes
HDR SupportHDR10, HDR10+, Dolby Vision, HLG
eARCYes
Auto Low Latency Mode (ALLM)Yes
Variable Refresh Rate (VRR)Yes
Quick Frame Transport (QFT)Yes
Dolby AtmosYes
Dolby Atmos Height VirtualizationYes
DTS:XYes
DTS Virtual:XYes
IMAX EnhancedYes
Auro-3DYes
HEOS Multi-roomYes
HEOS Built-inYes
AirPlay 2Yes
Wi-FiYes
BluetoothYes
EthernetYes
USB PortYes
Phono InputYes
