Service Manual 1000660 T5 1000661 T10 1000665 PB5 1000666 PB10 Ecoboiler 231109.doc Page 17 of 22
4.7.
4.7.4.7.
4.7. Tank Components
The tank internals are detailed below. Care should be taken when cleaning inside the tank.
The level probes provide much of the control inputs into the PCB and are critical to the operation of
the machine. The wiring to these should be checked regularly and the probes themselves should be
cleaned whenever the machine is serviced.
There are 3 level probes on the 10L Ecoboiler versions and 2 level probes on the 5L versions.
The Ecoboiler T10 tank is shown below – only the low level probe is visible in the picutre.
4.8.
4.8.4.8.
4.8. Descaling Procedure
To descale the machine thouroughly:
•
Unplug the machine.
•
Disconnect from the water supply.
•
Drain as much water from the tank as possible.
•
Remove the lids and allow the machine to cool completely.
•
Drain all the water from the machine.
•
Attempt to remove as much scale as possible by hand.
•
Reconnect machine and start up once again.
•
Add a descale solution (follow instructions as given). Flush the machine thouroughly before
use
Probe Assembly (2300463) – low position
Thermistor Pocket – ensure that this is not
touching the element.
