The M3310 HMI Controller
About the M3310 HMI Controller
The M3310 HMI Controller is the interface for various equipment and workstations in the food
processing industry. The user interacts with the controller via a touch panel and a large graph
ical LCD display. The M3310 HMI Controller is powered by CAN bus.
Figure 2 M3310 HMI Controller, front view
The M3310 HMI Controller is built on a Freescale ARM technology and runs a Linux real-time
operating system that offers a range of connections to other equipment:
l 2x Standard 1 Gbit Ethernet network and various protocols, for example, Powerlink, Eth
ercat, TCP, and IP
l USB Serial bus with two host ports and two for internal use
l RS232 (one serial port)
l Possible to service the controller remotely via the internet
l Agraphical high-contrast color display with a LED backlight
l Built-in battery backup for graceful power down
l CANOpen master
l USB host
The controller is a CANOpen master and USB host, and can be used as a human-machine inter
face and for real-time observation and performance monitoring.
Several software applications are available for the controller, and descriptions of those are
available in separate documentation.
160317ENG 5
