Technical Specifications
Figure 1 The measurements for M3310 HMI Controller
Manufacturer:
Marel ehf.
Dimensions:
Outer
dimensions
408 x 366 x 120 mm (16 1/16 x 14 7/16 x 4 3/4 )" (W x H x D)
w. mountings
Weight 4.5 kg (9.9 lbs)
Construction:
Material AISI 316 stainless steel
Environmental
protection
IEC 529-IP69K, wash-down environment (PW12)
Cleaning Wash with water and ordinary soap. Avoid high-pressure water jets for
cleaning.
Mounting Adjustable wall or table mounting bracket.
Hardware:
Disk eMMC 8 GB SSD, SD Flash Card, SATA 3.0 Gbps
CPU & RAM ARM Quad Core 800 Mhz, DDR3 2 Gigabyte
Display 10.4" TFT color display, 1024 x 768 pixel, LED backlight
Status
Indicators
Dual color LED
LEDstatus:
Green: Normal operation
Yellow (red + green): Screen saver
Touch screen Resistive, 4-wire technology, accuracy 3%
Connectivity:
Serial I/O RS-232, 1200 - 115200 Baud
Ethernet 2 x IEEE 802.3, 10/100/100 twisted-pair interface
M3310 HMI Controller User Manual Introduction
2 160317ENG
