The M3310 HMI Controller includes stainless steel wall brackets with a tilting option. These
bracket can be fastened with screws to other equipment or onto a tabletop. The controller is
supplied with standard mounting lugs. Various other mounting solutions are supported.
The main characteristics of the M3310 HMI Controller are a stainless construction and water
tight design. The M3310 HMI Controller is encased in a water-resistant AISI316 stainless steel
housing rated to the IP69K standard. The display is a 10.4” 1024 x 768 pixel TFTcolor LCD,
LEDbacklit, with a touch screen designed to withstand the harshest treatment.
Internally, this is a single board design which accepts an industrial 24 VDC power via cable.
The Communication is conducted via CAN bus, Ethernet, USB, and Serial RS232. Cable con
nections are all routed through a single multi-hole cable gland in the bottom of the enclosure.
The enclosure is opened from below by removing two screws. After opening the enclosure,
there is easy access to all the internal parts.
The controller can be serviced remotely via the Internet.
Initial Inspection
Prior to use, inspect the controller for damage incurred during shipment. If the controller has
been damaged, contact your local Marel service center immediately.
M3310 HMI Controller User Manual The M3310 HMI Controller
6 160317ENG
